Features
VLAN support: Yes
Maximum data transfer rate (2.4 GHz): 573.5 Mbit/s
Maximum data transfer rate (5 GHz): 1201 Mbit/s
Maximum indoor range: 175 m
Quality of Service (QoS) support: Yes
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Networking standards: IEEE 802.11ax, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
5 GHz: Yes
Maximum data transfer rate: 1770 Mbit/s
MIMO: Yes
2.4 GHz: Yes
Design
Cable lock slot type: Kensington
Placement: Wall
Cable lock slot: Yes
Product colour: White
LED indicators: Status
Power
Power consumption (max): 9 W
Power over Ethernet (PoE): Yes
Security
Number of SSID supported: 32
Security algorithms: WPA, WPA2-PSK, WPA2, WPA3, WEP
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -10 - 60 °C
Operating temperature (T-T): 0 - 45 °C
Weight & dimensions
Height: 40.8 mm
Depth: 180.4 mm
Width: 180.4 mm
Weight: 443 g
Packaging data
Package height: 79 mm
Package width: 228.5 mm
Package depth: 220 mm
Package weight: 774 g
Protocols
Supported network protocols: IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
Antenna
Antenna gain level (max): 4 dBi
Antenna type: Internal
Logistics data
Harmonized System (HS) code: 85176990
