Design
Rack mounting: Yes
Form factor: 1U
Product colour: Black
LED indicators: Yes
Power
Power supply included: Yes
Power consumption (max): 26 W
AC input frequency: 50/60 Hz
Power source: AC
AC input voltage: 100 - 240 V
Security
DHCP features: DHCP client, DHCP relay
SSH/SSL support: Yes
IGMP snooping: Yes
Access Control List (ACL): Yes
Loop protection: Yes
Password protection: Yes
Security algorithms: SNMPv2, SNMP, SNMPv3
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Switch layer: L2
MIB support: Y
Cloud-managed: Yes
Configuring Location Settings (CLI): Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Web-based management: Yes
Weight & dimensions
Height: 44 mm
Depth: 212 mm
Weight: 2.5 kg
Width: 442 mm
Network
10G support: No
Port mirroring: Yes
Number of VLANs: 4096
Spanning tree protocol: Yes
Broadcast storm control: Yes
Flow control support: Yes
VLAN support: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Networking standards: IEEE 802.3at, IEEE 802.1s, IEEE 802.3af, IEEE 802.3az, IEEE 802.1x
Packaging content
Manual: Yes
Ports & interfaces
Combo SFP ports quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports quantity: 24
Logistics data
Customs product code (TARIC): 85176200
Country of origin: Taiwan
Data transmission
MAC address table: 8000 entries
Throughput: 52 Gbit/s
Jumbo frames: 9000
Jumbo frames support: Yes
Packet forwarding rate (1 Gbps): 38.69 pps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
