Design
Form factor: 1U
Rack mounting: Yes
LED indicators: Yes
Product colour: Black
Power
Power supply included: Yes
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power source: AC
Power consumption (max): 240 W
Security
Security algorithms: SNMPv2, SNMP, SNMPv3
Loop protection: Yes
DHCP features: DHCP client, DHCP relay
Access Control List (ACL): Yes
IGMP snooping: Yes
Password protection: Yes
SSH/SSL support: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
MIB support: Y
Web-based management: Yes
Configuring Location Settings (CLI): Yes
Switch layer: L2
Cloud-managed: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Height: 44 mm
Width: 442 mm
Weight: 2.5 kg
Depth: 212 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.1s, IEEE 802.1x, IEEE 802.3af, IEEE 802.3az
VLAN support: Yes
Spanning tree protocol: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Port mirroring: Yes
Broadcast storm control: Yes
Flow control support: Yes
Number of VLANs: 4096
10G support: No
Packaging content
Manual: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 2
Power connector: AC-in jack
Logistics data
Country of origin: Taiwan
Customs product code (TARIC): 85176200
Data transmission
Jumbo frames support: Yes
Throughput: 52 Gbit/s
Packet forwarding rate (1 Gbps): 38.69 pps
Jumbo frames: 9000
MAC address table: 8000 entries
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 185 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 24
Multicast features
Multicast support: Yes
