Technical details
Lens mount interface: M12
Design
Form factor: Bullet
Protection features: Water resistant, Dust resistant
Housing material: Plastic, Metal
International Protection (IP) code: IP67
Product colour: White
Mounting type: Ceiling/wall
Power
DC output voltage: 12
Power source type: DC
Power consumption (typical): 9.8 W
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Depth: 178.3 mm
Height: 71 mm
Weight: 738 g
Width: 192.6 mm
Network
Bluetooth: No
Wi-Fi: No
Ethernet LAN: No
Performance
Day/night mode: Yes
Placement supported: Outdoor
Languages support: English
Built-in light: Yes
Wide Dynamic Range (WDR): Yes
Type: CCTV security camera
Connectivity technology: Wired
Number of languages: 1
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Storage
Built-in HDD: No
Ports & interfaces
BNC output ports: 1
DC-in jack: Yes
Camera
Camera shutter speed: 1/25 - 1/50000 s
Minimum illumination: 0 lx
White balance: Auto, Manual
Angle of rotation: 360°
Tilt angle range: 0 - 180°
Pan range: 0 - 360°
Lens viewing angle, diagonal: 92°
Lens viewing angle, vertical: 42°
Lens viewing angle, horizontal: 78°
Image sensor
Sensor type: CMOS
Video
Total megapixels: 2 MP
Gain control type: Auto
Back Light Compensation (BLC): Yes
Image quality adjustment: Sharpness, Brightness
Highlight Compensation (HLC): Yes
Digital Wide Dynamic Range (DWDR): Yes
Maximum resolution: 1920 x 1080 pixels
Frame rate: 30 fps
Analog signal format system: PAL, NTSC
Night vision
Night vision distance: 60 m
LED type: IR/White
Night vision: Yes
Lens system
Maximum aperture number: 2
Fixed focal length: 3.6 mm
