Technical details
Lens mount interface: M16
Iris: Yes
Design
Protection features: Dust resistant, Water resistant
International Protection (IP) code: IP67
Housing material: Metal
Form factor: Bullet
Product colour: White
Mounting type: Wall
Power
Power consumption (max): 7 W
Power source type: DC, PoE
DC output voltage: 12
Power consumption (Power over Ethernet (PoE)): 8.5 W
DC output current: 0.58 A
Security
Human and vehicle targets classification: Yes
Digest authentication: Yes
Password reset via email: Yes
Security algorithms: EAP-MD5, EAP-LEAP, EAP-TLS
Pixel counter: Yes
Automatic Network Replenishment (ANR): Yes
Active tampering alarm: Yes
HTTPS encryption: Yes
Heartbeat: Yes
Mirror: Yes
Privacy protection: Yes
Digital watermark: Yes
IP address filtering: Yes
Video motion detection: Yes
Password protection: Yes
Network access storage (NAS): Yes
Audit log: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 60 °C
Management features
Reset button: Yes
Web-based management: Yes
Behavior analysis: Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
Weight & dimensions
Diameter: 7.44 cm
Weight: 525 g
Length: 179.2 mm
Network
Client interoperability: iVMS-4200, Hik-Connect, Hik-Central
Wi-Fi: No
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Quality of Service (QoS) support: Yes
Bluetooth: No
Number of simultaneous live view channels: 6 channels
User access level: Administrator, Operator, User
Live view: Yes
Number of users: 32 user(s)
Performance
Wide Dynamic Range (WDR): Yes
Built-in light: Yes
Type: IP security camera
Connectivity technology: Wired
Number of languages: 33
Dynamic range: 130 dB
Placement supported: Outdoor
Infrared (IR) cut-off filter: Yes
Languages support: Multi
Day/night mode: Yes
Packaging data
Package height: 117 mm
Package weight: 750 g
Package width: 234 mm
Package depth: 120 mm
Packaging content
Number of cameras: 1
Audio
Signal-to-Noise Ratio (SNR): 52 dB
Storage
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Card reader integrated: Yes
Maximum memory card size: 512 GB
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0 lx
Pan range: 0 - 360°
Camera shutter speed: 1/3 - 1/100000 s
Angle of rotation: 360°
Tilt angle range: 0 - 90°
Lens viewing angle, horizontal: 90°
Lens viewing angle, diagonal: 109.4°
Lens viewing angle, vertical: 45.8°
Number of Privacy masking areas: 4
Image sensor
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Progressive scan: Yes
Number of sensors: 1
Sensor type: CMOS
Video
Noise reduction technology: 3D noise reduction
Noise reduction: Yes
Back Light Compensation (BLC): Yes
Region of Interest (ROI) encoding: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate: 32 Kbps - 16 Mbps
Highlight Compensation (HLC): Yes
Total megapixels: 6 MP
Frame rate: 30 fps
Maximum resolution: 3200 x 1800 pixels
Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 360, 3200 x 1800, 640 x 480 (VGA), 2688 x 1520, 1280 x 720 (HD 720)
Video streaming: Yes
Image quality adjustment: Brightness, Sharpness, Contrast, Saturation
Privacy masking: Yes
Video compression formats: M-JPEG, H.265+, H.264+, H.265, H.264
Night vision
LED type: IR/White
Night vision distance: 40 m
Night vision: Yes
Infra-red wavelength: 850 nm
Lens system
Detect distance: 109 m
Fixed focus: Yes
Maximum aperture number: 1
Identify distance: 10 m
Observe distance: 43 m
Recognize distance: 21 m
Number of lenses: 1
Fixed focal length: 4 mm
Sustainability
Compliance certificates: CB, Low Voltage Directive (LVD), RoHS, CE, UL, KC, Industry Canada (IC), RCM, BIS
Sustainability compliance: Yes
