Technical details
General Product Safety Regulation (GPSR) URL: https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true
Compliance certificates: CECP
Master (outer) cases per pallet layer: 3 pc(s)
Replacement cartridges: CF289A HP 89A Black Original LaserJet Toner Cartridge (5,000 pages);CF289X HP 89X High Yield Black Original LaserJet Toner Cartridge (10,000 pages);CF289Y HP 89Y Extra High Yield Black Original LaserJet Toner Cartridge (20,000 pages)
Features
HP segment: Business
Printer fonts: PostScript, TrueType, PCL, Scalable, Windows
Page description languages: PCL 6, PDF 1.7, PostScript 3
Recommended duty cycle: 2000 - 7500 pages per month
Number of print cartridges: 1
Maximum duty cycle: 150000 pages per month
Printing colours: Black
Certification: CISPR 22:2008 (International) - Class A, CISPR32:2012 (International) - Class A, EN 55032:2012 (EU) - Class A, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010, EMC Directive 2014/30/EU, Issue 6 Class A. Other EMC approvals as required by individual countries.
Design
Product colour: White
Display: CGD
Display diagonal: 10.9 cm (4.3")
Built-in display: Yes
Market positioning: Business
Touchscreen: Yes
Control type: Buttons, Touch
Colour display: Yes
Power
Power consumption (PowerSave): 0.06 W
AC input frequency: 50/60 Hz
Power consumption (off): 0.06 W
AC input voltage: 220 - 240 V
Power consumption (ready): 7.6 W
Energy Star Typical Electricity Consumption (TEC): 1.257 kWh/week
Power consumption (printing): 601 W
Operational conditions
Operating temperature (T-T): 10 - 32.5 °C
Storage temperature (T-T): -20 - 40 °C
Operating relative humidity (H-H): 10 - 80%
Weight & dimensions
Weight: 16.3 kg
Depth: 376 mm
Pallet dimensions (W x D x H): 1200 x 1000 x 2476 mm
Width: 418 mm
Height: 481 mm
Network
Ethernet LAN data rates: 1000 Mbit/s
Bluetooth: Yes
Security algorithms: SSL/TLS, FIPS 140, IPSec, EAP-TLS, HTTPS, EAP-PEAP, SNMPv3
Ethernet LAN: Yes
Wi-Fi Direct: Yes
Network ready: Yes
Wi-Fi standards: 802.11b, Wi-Fi 4 (802.11n), 802.11g
Mobile printing technologies: Mopria Print Service, HP ePrint, Apple AirPrint, Google Cloud Print
Wi-Fi: Yes
System requirements
Windows operating systems supported: Windows 8.1, Windows 8.1 Pro, Windows 10 Pro, Windows 8, Windows 7 Ultimate, Windows 10 Enterprise, Windows 8 Enterprise, Windows 8.1 Enterprise, Windows 7 Professional, Windows 7, Windows 7 Starter, Windows 10, Windows 8 Pro, Windows 7 Enterprise
Mac operating systems supported: MacOS, Mac OS X 10.14 Mojave, Mac OS X 10.13 High Sierra, Mac OS X 10.12 Sierra
Other operating systems supported: iOS, Android
Linux operating systems supported: Yes
Performance
Processor frequency: 1200 MHz
Internal memory: 512 MB
Built-in processor: Yes
Sound pressure level (printing): 54 dB
Sound power level (printing): 6.8 dB
Memory slots: 1
Maximum internal memory: 1536 MB
Packaging data
Package width: 671 mm
Package weight: 22.6 kg
Package depth: 497 mm
Package height: 465 mm
Packaging content
Quick installation guide: Yes
Cables included: AC
Warranty card: Yes
Ports & interfaces
USB 2.0 ports quantity: 3
Standard interfaces: Ethernet, USB 2.0, Wireless LAN
Optional connectivity: Ethernet, Wireless LAN
Direct printing: Yes
USB port: Yes
Compatible operating systems: Windows Client OS (32/64 bit), Win10, Win8.1, Win 8 Basic, Win8 Pro, Win8 Enterprise, Win8 Enterprise N, Win7 Starter Edition SP1, UPD Win7 Ultimate, Mobile OS, iOS, Android, Mac, Apple macOS Sierra v10.12, Apple macOS High Sierra v10.13, Apple macOS Mojave v10.14, Discrete PCL6 Printer Driver, For more information on the supported operating systems go to http://support.hp.com, Enter your product name and search, Click on User Guides and enter your product name and search for User Guide, Search for your (Product Name) - User Guide, Search for the Supported Operating Systems section, UPD PCL6 / PS Printer Drivers, Supported Operating systems, For more information on the supported operating systems see http://www.hp.com/go/upd
Manufacturer warranty: One-year, next-business day, onsite warranty. Warranty and support options vary by product, country and local legal requirements.
Box contents: HP LaserJet Enterprise M507x Printer; HP Original LaserJet Toner Cartridge (5,000 pages); Regulatory flyer (CD replacement); Unpack flyer; Installation guide; Power cord; Warranty cards; Support flyers/phone number list
Recommended system requirements: 2 GB available hard disk space; Internet connection; USB port; Internet browser; for additional OS hardware requirements.
2 GB available hard disk space; Internet connection or USB port; OS hardware requirements.
Other features
Processor frequency: 1.2 GHz
UNSPSC-code: 43212105
Typical electricity consumption (TEC) number: Blue Angel: 1.257 kWh/Week; Energy Star 3.0: 0.420 kWh/Week
Printing: Mono printing
Recommended humidity operating range: 30 - 70%
Acoustic power emissions (ready): 39 dB
Acoustic pressure emissions bystander (ready): 24 dB
Envelope feeder: No
Recommended operating temperature range (T-T): 15 - 27 °C
Printing
Time to first page (black, normal): 5.9 s
Print resolution black: 1200 x 1200 DPI
Colour: No
Secure printing: Yes
Duplex printing: Yes
Watermark printing: Yes
Maximum resolution: 1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter): 43 ppm
Print margins (top, bottom, right, left): 4.3 mm
Warm-up time: 150 s
Print technology: Laser
Duplex printing mode: Auto
Logistics data
Harmonized System (HS) code: 84433210
Pallet gross weight: 299.6 kg
Layers per pallet: 5 pc(s)
Input & output capacity
Paper tray 1 input capacity: 100 sheets
Maximum output capacity: 250 sheets
Total output capacity: 250 sheets
Total input capacity: 1200 sheets
Maximum input capacity: 2300 sheets
Multi-Purpose tray input capacity: 100 sheets
Paper tray 2 input capacity: 550 sheets
Multi-Purpose tray: Yes
Total number of input trays: 3
Maximum number of input trays: 5
Paper handling
Custom media length: 127 - 355.6 mm
Maximum ISO A-series paper size: A4
Custom media width: 76.2 - 215.9 mm
ISO B-series sizes (B0...B9): B5
Non-ISO print media sizes: Oficio, 16K
Envelopes sizes: C6, DL, B5, C5
Photo paper sizes: 10x15
JIS B-series sizes (B0...B9): B5, B6
Paper tray media types: Envelopes, Transparencies, Labels, Rough paper, Plain paper, Recycled paper, Card stock, Bond paper
ISO A-series sizes (A0...A9): A4, A5, A6
ISO C-series sizes (C0...C9): C6, C5
Paper tray media weight: 60 - 200 g/m²
Brand-specific features
HP GTIN (EAN/UPC): 886112880644
HP GTIN (EAN/UPC) with options: (301) 888182031704; (BGX) 888182034613; (BGY) 888182034620
HP ePrint: Yes
HP Auto-On/Auto-Off: Yes
HP Dynamic security: Yes
Sustainability
Doesn't contain: Mercury
Sustainability compliance: Yes
Sustainable technologies and materials: 50% post-consumer recycled plastic
Sustainability certificates: EPEAT Silver, Blue Angel, ENERGY STAR
Carbon footprint
Total carbon emissions, w/o use phase (kg of CO2e): 19
Carbon emissions, manufacturing (kg of CO2e): 58
Carbon emissions, logistics (kg of CO2e): 3
Total carbon footprint (kg of CO2e): 6.3
