Technical details
General Product Safety Regulation (GPSR) URL: https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true
Processor
Processor cache type: L3
Processor base power: 65 W
Processor manufacturer: Intel
Processor model: i5-14500
Processor cores: 14
Efficient-core Max Turbo Frequency: 3.7 GHz
Performance cores: 6
Processor cache: 24 MB
Processor threads: 20
Maximum turbo power: 154 W
Efficient-core base frequency: 1.9 GHz
Performance-core Max Turbo Frequency: 5 GHz
Performance-core base frequency: 2.6 GHz
Efficient cores: 8
Processor family: Intel® Core™ i5
Processor generation: Intel® Core™ i5 (14th gen)
Processor boost frequency: 5 GHz
Graphics
On-board graphics card family: Intel® UHD Graphics
On-board graphics card: Yes
On-board GPU manufacturer: Intel
Discrete graphics card: No
Discrete graphics card model: Not available
On-board graphics card model: Intel UHD Graphics 770
Memory
Internal memory: 16 GB
Memory clock speed: 4800 MHz
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 1 x 16 GB
Memory slots: 2x DIMM
Maximum internal memory: 64 GB
Design
Number of 3.5" bays: 1
Chassis type: SFF
Product colour: Black
Power
Power supply input frequency: 50/60 Hz
Power supply input voltage: 100 - 240 V
Power supply: 240 W
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 10 - 35 °C
Weight & dimensions
Package height: 499 mm
Package depth: 205 mm
Depth: 95 mm
Width: 270 mm
Package width: 394 mm
Height: 308 mm
Package weight: 7.25 kg
Weight: 4.2 kg
Network
Mobile network connection: No
Ethernet LAN: Yes
Wi-Fi: Yes
Cabling technology: 10/100/1000Base-T(X)
Bluetooth: Yes
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Performance
Password protection type: User, Power on, BIOS
Trusted Platform Module (TPM) version: 2.0
Password protection: Yes
Product type: PC
Market positioning: Proven productivity
Motherboard chipset: Intel Q670
Audio chip: Realtek ALC3252
Trusted Platform Module (TPM): Yes
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Display
Display included: No
Software
Operating system architecture: 64-bit
Operating system installed: Windows 11 Pro
Storage
SSD capacity: 512 GB
Total storage capacity: 512 GB
NVMe: Yes
Total SSDs capacity: 512 GB
SSD interface: PCI Express
Number of SSDs installed: 1
Storage media: SSD
Number of storage drives installed: 1
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Combo headphone/mic port: Yes
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI version: 1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Line-out: Yes
USB 2.0 ports quantity: 2
DisplayPorts quantity: 1
DisplayPort version: 1.4
Brand-specific features
HP Security tools: Padlock loop; Trusted Platform Module (TPM) 2.0; Integrated accessories cable lock; Slim cable lock
HP Support Assistant: Yes
HP Management tools: HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant (download); HP Client Management Script Library (download); HP Manageability Integration Kit Gen 4 (download)
HP segment: Business
Sustainability
Sustainability certificates: ENERGY STAR
Sustainability compliance: Yes
Carbon footprint
Total carbon footprint (kg of CO2e): 230
Carbon emissions, manufacturing (kg of CO2e): 173
Carbon emissions, logistics (kg of CO2e): 2
Carbon emissions, end-of-life (kg of CO2e): 1
Total carbon emissions, w/o use phase (kg of CO2e): 55
