Technical details
General Product Safety Regulation (GPSR) URL: https://support.hp.com/gb-en/product/setup-user-guides/hp-color-laser-mfp-170-printer-series/model/24494366?sku=4ZB96A ; http://h10032.www1.hp.com/ctg/Manual/c06266695.pdf ; http://h10032.www1.hp.com/
Design
Product colour: Black
Market positioning: Business
Feet colour: Black, Silver
Colour name: Jet black
Detachable stand: Yes
Power
Power consumption (off): 0.3 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power supply type: Internal
Power consumption (standby): 0.5 W
Energy consumption (SDR) per 1000 hours: 14 kWh
Energy efficiency class (HDR): D
Power consumption (typical): 33 W
Energy efficiency scale: A to G
Power consumption (max): 223 W
Energy efficiency class (SDR): D
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 20 - 80%
Weight & dimensions
Height (with stand): 503.2 mm
Width (with stand): 539.4 mm
Depth (with stand): 189.5 mm
Weight (with stand): 9.5 kg
Depth (without stand): 18.6 mm
Width (without stand): 212.4 mm
Height (without stand): 123.7 mm
Weight (without stand): 4.99 kg
Network
Remotely operated: Yes
Ethernet LAN: Yes
Performance
Infrared (IR) sensor: Yes
Flicker-free technology: Yes
AMD FreeSync: No
Low Blue Light technology: Yes
HP segment: Business
Fast charging: Yes
NVIDIA G-SYNC: No
Packaging data
Warranty card: Yes
Package width: 621 mm
Package type: Box
Package height: 393 mm
Package weight: 9.5 kg
Package depth: 140 mm
Bundled software: HP Display Center; HP Client Management Script Library
Packaging content
Quick start guide: Yes
Stand included: Yes
Cables included: DisplayPort, USB Type-C to USB Type-C, USB Type-A to USB Type-B, AC
Display
Native aspect ratio: 16:9
Aspect ratio: 16:9
Display resolution: 1920 x 1080 pixels
Display diagonal: 60.5 cm (23.8")
LED backlight: Yes
Display surface: Matt
Display brightness (typical): 350 cd/m²
Response time: 5 ms
Response time measurement type: GTG (Gray to Gray)
Screen shape: Flat
HD type: Full HD
Display technology: LCD
Viewable size, horizontal: 52.7 cm
Display brightness: 350 cd/m²
Viewable size, vertical: 29.6 cm
Viewable size diagonal: 6.05 cm
Panel type: IPS
Display diagonal (metric): 60.5 cm
Backlight type: Edge LED
Contrast ratio (typical): 1500:1
Colour gamut: 100%
Maximum refresh rate: 100 Hz
Surface hardness: 3H
Pixel density: 93 ppi
Anti-glare screen: Yes
Display bezel technology: Micro-Edge
Response time (fast): 5 ms
Haze rate: 25%
Colour depth: 8 bit
Supported graphics resolutions: 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 640 x 480 (VGA), 1024 x 768 (XGA), 1440 x 900 (WXGA+), 1280 x 800, 720 x 400, 1680 x 1050 (WSXGA+), 1600 x 900, 1920 x 1080 (HD 1080), 800 x 600 (SVGA)
Contrast ratio (dynamic): 10000000:1
Display number of colours: 16.7 million colours
Pixel pitch: 0.27 x 0.27 mm
Viewing angle, vertical: 178°
Viewing angle, horizontal: 178°
Vertical scan range: 50 - 100 Hz
Touchscreen: No
Horizontal scan range: 30 - 115 kHz
sRGB coverage (typical): 100%
Colour gamut standard: sRGB
Multimedia
Built-in microphone: Yes
Built-in speaker(s): Yes
Number of speakers: 4
Built-in camera: Yes
RMS rated power: 12 W
Megapixel (approx.): 5 MP
Ergonomics
Cable lock slot: Yes
Tilt angle range: -5 - 23°
Adjustable height (max): 15 cm
Pivot: Yes
Swivelling: Yes
Swivel angle range: -45 - 45°
Pivot angle: -90 - 90°
Panel mounting interface: 100 x 100 mm
VESA mounting: Yes
Height adjustment: Yes
Tilt adjustment: Yes
On Screen Display (OSD): Yes
Cable lock slot type: Kensington
Ports & interfaces
DisplayPorts quantity: 1
DisplayPort version: 1.4
HDCP: Yes
Number of USB Type-C upstream ports quantity: 1
Built-in KVM switch: Yes
Headphone out: Yes
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
HDMI: Yes
Audio input: Y
Headphone connectivity: 3.5 mm
Audio output: Yes
USB Type-A downstream ports quantity: 3
USB Type-C DisplayPort Alternate Mode: Yes
USB Power Delivery (USB PD): Yes
USB Type-C downstream ports quantity: 1
USB Power Delivery up to: 100 W
Built-in USB hub: Yes
Number of USB Type-B upstream ports quantity: 1
Headphone outputs: 1
HDMI ports quantity: 1
HDMI version: 2.0
DisplayPort out version: 1.4
DisplayPort out quantity: 1
Packaging content: Monitor; DisplayPort™ cable; Warranty card; USB Type-A to B cable; Quick Setup Poster; 1 USB Type-C to Type-C cable; AC power cord
Manufacturer warranty: HP three-year limited warranty
Certification: Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL; CEL Grade 1; cTUVus; EAC; FCC; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; Vietnam MEPS; WEEE; ISC; California Energy Commission (CEC); UAE; TGM; Ukraine certificates; TÜV Flicker free certified; NRCS; PSE; GS; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Korea MEPS; Australian-New Zealand DoC; EMF
Other features
Country of origin: Thailand, China
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Weight: 9.5 kg
Supplied AC adapter type: 198122901920
UNSPSC-code: 43211902
Ethernet LAN (RJ-45) ports: 1
Compliance certificates: BIS, CB, EAC, Federal Communications Commission (FCC), BSMI, CE, CECP, CCC
Sustainability
Sustainability certificates: ENERGY STAR, TCO, EPEAT
