Technical details
General Product Safety Regulation (GPSR) URL: https://support.hp.com/gb-en/product/setup-user-guides/hp-color-laser-mfp-170-printer-series/model/24494366?sku=4ZB96A ; http://h10032.www1.hp.com/ctg/Manual/c06266695.pdf ; http://h10032.www1.hp.com/
Design
Product colour: Black
Feet colour: Black, Silver
Colour name: Jet black
Market positioning: Business
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (off): 0.3 W
Power consumption (max): 58 W
Power consumption (typical): 22 W
Power supply type: Internal
Energy efficiency class (HDR): C
Energy efficiency class (SDR): C
Energy consumption (SDR) per 1000 hours: 12 kWh
Power consumption (standby): 0.5 W
Energy efficiency scale: A to G
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating altitude: 0 - 5000 m
Storage relative humidity (H-H): 20 - 80%
Operating relative humidity (H-H): 5 - 95%
Non-operating altitude: 0 - 12192 m
Weight & dimensions
Width (with stand): 532.8 mm
Depth (with stand): 189.5 mm
Height (with stand): 517.5 mm
Height (without stand): 342.9 mm
Width (without stand): 532.8 mm
Depth (without stand): 47 mm
Weight (with stand): 5.1 kg
Performance
NVIDIA G-SYNC: No
Flicker-free technology: Yes
HP segment: Business
Low Blue Light technology: Yes
AMD FreeSync: No
Packaging data
Package type: Box
Package weight: 7.4 kg
Package height: 411 mm
Package depth: 140 mm
Package width: 621 mm
Warranty card: Yes
Bundled software: HP Display Center; HP Client Management Script Library
Packaging content
Quick start guide: Yes
Cables included: HDMI, DisplayPort, USB Type-A to USB Type-B, AC
Display
Display resolution: 1920 x 1200 pixels
Display brightness (typical): 350 cd/m²
Display surface: Matt
Viewing angle, horizontal: 178°
HD type: WUXGA
Contrast ratio (dynamic): 10000000:1
Screen shape: Flat
Supported graphics resolutions: 1280 x 1024 (SXGA), 720 x 576, 1024 x 768 (XGA), 1440 x 900 (WXGA+), 720 x 480, 1280 x 800, 640 x 480 (VGA), 1920 x 1200 (WUXGA), 1680 x 1050 (WSXGA+), 720 x 400, 1600 x 900, 1920 x 1080 (HD 1080), 800 x 600 (SVGA), 1280 x 720 (HD 720)
Response time: 5 ms
Display diagonal: 61 cm (24")
LED backlight: Yes
Aspect ratio: 16:10
Native aspect ratio: 16:10
Vertical scan range: 50 - 100 Hz
Pixel pitch: 0.27 x 0.27 mm
Display number of colours: 16.7 million colours
Viewing angle, vertical: 178°
Horizontal scan range: 30 - 130 kHz
Response time measurement type: GTG (Gray to Gray)
Display brightness: 350 cd/m²
Touchscreen: No
Colour gamut: 100%
Colour depth: 8 bit
Viewable size, vertical: 32.4 cm
Viewable size, horizontal: 51.8 cm
Surface hardness: 3H
Anti-glare screen: Yes
Panel type: IPS
Display bezel technology: Micro-Edge
Display technology: LCD
Contrast ratio (typical): 1500:1
Display diagonal (metric): 61 cm
Pixel density: 94 ppi
Haze rate: 25%
sRGB coverage (typical): 100%
Backlight type: Edge LED
Maximum refresh rate: 100 Hz
Colour gamut standard: sRGB
Multimedia
Built-in camera: No
Built-in speaker(s): No
Ergonomics
Cable lock slot: Yes
Tilt angle range: -5 - 23°
Adjustable height (max): 15 cm
Pivot angle: -90 - 90°
Swivelling: Yes
Pivot: Yes
Panel mounting interface: 100 x 100 mm
Tilt adjustment: Yes
VESA mounting: Yes
Swivel angle range: -45 - 45°
Height adjustment: Yes
On Screen Display (OSD): Yes
Ports & interfaces
HDCP: Yes
DisplayPorts quantity: 1
DisplayPort version: 1.2
Headphone out: No
Built-in USB hub: Yes
USB upstream port type: USB Type-B
HDMI version: 1.4
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
HDMI: Yes
USB Type-A downstream ports quantity: 4
Number of USB Type-B upstream ports quantity: 1
HDMI ports quantity: 1
DisplayPort out version: 1.2
Certification: BIS; BSMI; CB; CCC; CE; CECP; CEL; cTUVus; EAC; FCC; GS Mark; ICES; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; VCCI; WEEE; ISC; California Energy Commission (CEC); WW application; UAE; TGM; Ukraine certificates; NRCS; PSE; Ukraine EE; TÜV Low Blue Light Hardware Solution certified; Works with Chromebook certified; Korea MEPS; CEL Grade 2; Australian-New Zealand DoC; EMF
Packaging content: Monitor; DisplayPort™ cable; HDMI cable; Warranty card; USB Type-B to A cable; Quick Setup Poster; AC power cord
Manufacturer warranty: HP three-year limited warranty
Other features
Weight: 5.1 kg
Supplied AC adapter type: 198122901920
Compliance certificates: BIS, CECP, BSMI, EAC, GS mark, CCC, CB, Federal Communications Commission (FCC), CE
UNSPSC-code: 43211902
Sustainability
Sustainability certificates: EPEAT, ENERGY STAR, TCO
