Technical details
General Product Safety Regulation (GPSR) URL: https://support.hp.com/gb-en/product/setup-user-guides/hp-color-laser-mfp-170-printer-series/model/24494366?sku=4ZB96A ; http://h10032.www1.hp.com/ctg/Manual/c06266695.pdf ; http://h10032.www1.hp.com/
Design
Product colour: Black
Detachable stand: Yes
Feet colour: Black, Silver
Market positioning: Business
Power
Energy efficiency class (SDR): E
AC input frequency: 50/60 Hz
Energy efficiency class (HDR): E
Power supply type: Internal
Energy consumption (SDR) per 1000 hours: 19.2 kWh
AC input voltage: 100 - 240 V
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
Power consumption (standby): 0.5 W
Power consumption (typical): 26.4 W
Power consumption (max): 160 W
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 20 - 80%
Weight & dimensions
Width (with stand): 531.7 mm
Weight (with stand): 5.2 kg
Height (with stand): 521.4 mm
Width (without stand): 531.7 mm
Height (without stand): 342.9 mm
Depth (with stand): 195 mm
Depth (without stand): 38.5 mm
Network
Ethernet LAN: Yes
Remotely operated: Yes
Performance
HP segment: Business
Fast charging: Yes
Flicker-free technology: Yes
VESA Adaptive Sync support: Yes
Low Blue Light technology: Yes
AMD FreeSync: No
NVIDIA G-SYNC: No
Packaging data
Warranty card: Yes
Package type: Box
Package width: 625 mm
Package weight: 7.8 kg
Package height: 415 mm
Package depth: 142 mm
Bundled software: HP Display Center; HP Client Management Script Library
Packaging content
Quick start guide: Yes
Stand included: Yes
Cables included: DisplayPort, HDMI, AC, USB Type-C to USB Type-C
Display
Anti-glare screen: Yes
Surface hardness: 3H
Display surface: Matt
Display resolution: 1920 x 1200 pixels
Screen shape: Flat
Backlight type: Edge LED
sRGB coverage (typical): 99%
Touchscreen: No
Display brightness: 350 cd/m²
Viewable size, vertical: 32.4 cm
LED backlight: Yes
Response time measurement type: GTG (Gray to Gray)
Display diagonal: 61 cm (24")
Display brightness (peak): 350 cd/m²
Response time: 5 ms
Panel type: IPS
Display diagonal (metric): 61 cm
Display technology: LCD
Native aspect ratio: 16:10
Pixel density: 94 ppi
Viewable size, horizontal: 51.8 cm
Haze rate: 25%
Display brightness (typical): 350 cd/m²
Colour gamut: 99%
Supported graphics resolutions: 1680 x 1050 (WSXGA+), 1024 x 768 (XGA), 1440 x 900 (WXGA+), 1280 x 800, 1920 x 1080 (HD 1080), 800 x 600 (SVGA), 720 x 400, 1280 x 1024 (SXGA), 1600 x 900, 640 x 480 (VGA), 1920 x 1200 (WUXGA)
Maximum refresh rate: 100 Hz
HD type: WUXGA
Colour gamut standard: Rec. 709, DCI-P3, sRGB
Aspect ratio: 16:10
Contrast ratio (typical): 1500:1
Colour depth: 8 bit
Display bezel technology: Micro-Edge
Viewing angle, vertical: 178°
Horizontal scan range: 30 - 75 kHz
Pixel pitch: 0.27 x 0.27 mm
Display number of colours: 16.7 million colours
Vertical scan range: 50 - 100 Hz
Contrast ratio (dynamic): 10000000:1
Viewing angle, horizontal: 178°
Multimedia
Built-in camera: No
Built-in speaker(s): No
Ergonomics
Cable lock slot: Yes
Panel mounting interface: 100 x 100 mm
Picture-in-Picture: Yes
Tilt adjustment: Yes
Swivelling: Yes
Pivot angle: 0 - 90°
Swivel angle range: -45 - 45°
Tilt angle range: -5 - 20°
VESA mounting: Yes
Height adjustment: Yes
Pivot: Yes
Adjustable height (max): 15 cm
On Screen Display (OSD): Yes
Ports & interfaces
USB Power Delivery up to: 100 W
HDMI version: 2.0
USB Type-C DisplayPort Alternate Mode: Yes
HDCP: Yes
DisplayPort version: 1.4
USB Type-C downstream ports quantity: 1
Number of USB Type-B upstream ports quantity: 1
DisplayPorts quantity: 1
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
HDMI: Yes
Built-in USB hub: Yes
USB upstream port type: USB Type-A, USB Type-B
USB Type-A downstream ports quantity: 4
USB Power Delivery (USB PD): Yes
HDMI ports quantity: 1
Manufacturer warranty: HP three-year limited warranty
Packaging content: Monitor; DisplayPort™ cable; HDMI cable; VESA Mount adapter; Warranty card; Quick Setup Poster; 1 USB Type-C to Type-C cable; AC power cord; Color calibration report
Certification: Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL; cTUVus; EAC; FCC; GS Mark; ISO 9241-307; KC; KCC; NOM; PSB; SEPA; TUV-S; VCCI; Vietnam MEPS; WEEE; ISC; Low blue light; WW application; UAE; Ukraine EE; Microsoft WHQL Certification (Windows 11 and Windows 10); Ukraine CoC; Ukraine DOC
Other features
Compliance certificates: CE, BIS, BSMI, Federal Communications Commission (FCC), CECP, CCC, CB, EAC, GS mark
UNSPSC-code: 43211902
Supplied AC adapter type: 198122901920
Weight: 5.2 kg
Depth: 38.5 mm
Country of origin: China
Ethernet LAN (RJ-45) ports: 1
Height: 342.9 mm
Width: 531.7 mm
Sustainability
Sustainability certificates: ENERGY STAR, TCO, EPEAT
Carbon footprint
Carbon emissions, end-of-life (kg of CO2e): 19
Carbon emissions, manufacturing (kg of CO2e): 108
Total carbon emissions, w/o use phase (kg of CO2e): 26
Carbon emissions, logistics (kg of CO2e): 5
Total carbon footprint (kg of CO2e): 160
