Technical details
General Product Safety Regulation (GPSR) URL: https://support.hp.com/gb-en/product/setup-user-guides/hp-color-laser-mfp-170-printer-series/model/24494366?sku=4ZB96A ; http://h10032.www1.hp.com/ctg/Manual/c06266695.pdf ; http://h10032.www1.hp.com/
Design
Product colour: Black
Market positioning: Business
Frameless design: Yes
Detachable stand: Yes
Feet colour: Silver, Black
Power
Power consumption (max): 215 W
Power consumption (off): 0.3 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (typical): 43 W
Power consumption (standby): 0.5 W
Energy consumption (HDR) per 1000 hours: 46 kWh
Power supply type: Internal
Energy efficiency class (SDR): F
Energy efficiency class (HDR): F
Energy consumption (SDR) per 1000 hours: 26 kWh
Energy efficiency scale: A to G
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 20 - 80%
Weight & dimensions
Depth (with stand): 225.2 mm
Width (with stand): 613.4 mm
Height (with stand): 540.5 mm
Weight (with stand): 6.5 kg
Height (without stand): 354 mm
Width (without stand): 613.4 mm
Depth (without stand): 74.5 mm
Network
Ethernet LAN: Yes
Remotely operated: Yes
Performance
NVIDIA G-SYNC: No
Flicker-free technology: Yes
AMD FreeSync: No
Low Blue Light technology: Yes
Fast charging: Yes
HP segment: Business
Packaging data
Package depth: 161 mm
Package width: 715 mm
Package type: Box
Package height: 455 mm
Package weight: 9.8 kg
Warranty card: Yes
Bundled software: HP Display Center; HP Client Management Script Library
Packaging content
Quick start guide: Yes
Cables included: Thunderbolt, DisplayPort, HDMI, AC, USB Type-C to USB Type-A
Stand included: Yes
Display
Response time measurement type: GTG (Gray to Gray)
Horizontal scan range: 30 - 140 kHz
Display brightness (typical): 400 cd/m²
Viewing angle, vertical: 178°
Supported graphics resolutions: 1280 x 720 (HD 720), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 800 x 600 (SVGA), 720 x 400, 640 x 480 (VGA), 1920 x 1200 (WUXGA), 1024 x 768 (XGA), 3840 x 2160, 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 2560 x 1440, 1280 x 1024 (SXGA), 1600 x 900
Screen shape: Flat
Display diagonal: 68.6 cm (27")
Vertical scan range: 29 - 60 Hz
LED backlight: Yes
Native aspect ratio: 16:9
Display surface: Matt
Display resolution: 3840 x 2160 pixels
Response time: 5 ms
Viewing angle, horizontal: 178°
Pixel pitch: 0.15 x 0.15 mm
HD type: 4K Ultra HD
Display number of colours: 1.07 billion colours
Aspect ratio: 16:9
Display technology: LCD
Backlight type: Edge LED
Touchscreen: No
Display diagonal (metric): 68.6 cm
Display brightness: 400 cd/m²
Pixel density: 163 ppi
High Dynamic Range (HDR) supported: Yes
sRGB coverage (typical): 100%
Viewable size, vertical: 33.6 cm
Viewable size, horizontal: 59.7 cm
Panel type: IPS Black
Anti-glare screen: Yes
Haze rate: 25%
High Dynamic Range (HDR) technology: DisplayHDR 400
Surface hardness: 3H
Colour depth: 10 bit
Colour gamut: 100%
Colour gamut standard: DCI-P3, sRGB
Contrast ratio (typical): 2000:1
Maximum refresh rate: 60 Hz
Multimedia
Built-in speaker(s): No
Built-in camera: No
Ergonomics
Adjustable height (max): 15 cm
Tilt angle range: -5 - 20°
Cable lock slot: Yes
Panel mounting interface: 100 x 100 mm
Swivelling: Yes
Tilt adjustment: Yes
VESA mounting: Yes
Height adjustment: Yes
On Screen Display (OSD): Yes
Pivot angle: -90 - 90°
Swivel angle range: -45 - 45°
Pivot: Yes
Picture-in-Picture: Yes
Ports & interfaces
DisplayPort version: 1.4
DisplayPorts quantity: 1
HDCP: Yes
Built-in USB hub: Yes
HDMI version: 2.0
HDMI ports quantity: 1
HDMI: Yes
Thunderbolt 4 ports quantity: 2
USB Type-C downstream ports quantity: 1
USB hub version: 3.2 Gen 2 (3.1 Gen 2)
USB Type-A downstream ports quantity: 5
Headphone out: No
USB Type-C DisplayPort Alternate Mode: Yes
Built-in KVM switch: Yes
USB Power Delivery up to: 100 W
USB upstream port type: USB Type-C
USB Power Delivery (USB PD): Yes
Certification: BIS; BSMI; CB; CCC; CE; CECP; CEL; EAC; FCC; ISO 9241-307; KC; KCC; NOM; PSB; RCM; SEPA; TUV-S; UL/CSA; VCCI; WEEE; ISC; Low blue light; ICE; UAE; GS; Ukraine EE; Belarus EE; Korea MEPS; CEL Grade 2
Packaging content: Monitor; Thunderbolt™ cable; DisplayPort™ cable; HDMI cable; Warranty card; Quick Setup Poster; 1 USB Type-C to Type-A cable; AC power cord; Color calibration report; VESA mount adapter
Other features
Supplied AC adapter type: 198122901920
Weight: 6.5 kg
Country of origin: China
Ethernet LAN (RJ-45) ports: 1
Depth: 74.5 mm
Width: 613.4 mm
Height: 354 mm
UNSPSC-code: 43211902
Compliance certificates: CCC, CE, BIS, CECP, CB, EAC, Federal Communications Commission (FCC), BSMI
Sustainability
Sustainability certificates: EPEAT, ENERGY STAR, TCO
Carbon footprint
Total carbon emissions, w/o use phase (kg of CO2e): 26
Total carbon footprint (kg of CO2e): 160
Carbon emissions, logistics (kg of CO2e): 5
Carbon emissions, end-of-life (kg of CO2e): 19
Carbon emissions, manufacturing (kg of CO2e): 108
