Features
Networking standards: IEEE 802.11ax, IEEE 802.11mc
2.4 GHz: Yes
Modulation: 16-QAM, BPSK, 64-QAM, QPSK, 256-QAM, CCK, 1024-QAM
Spread spectrum method: DSSS, OFDM
Frequency band: 20/40 (2.4 GHz), 20/40/80/(80+80) (5 GHz), and maximum peak data rate 2.9 Gbps
5 GHz: Yes
Maximum data transfer rate (2.4 GHz): 1148 Mbit/s
Auto MDI/MDI-X: Yes
MIMO: Yes
Maximum data transfer rate: 3550 Mbit/s
MIMO type: Multi User MIMO
Ethernet LAN data rates: 5000 Mbit/s
Maximum data transfer rate (5 GHz): 2402 Mbit/s
MACsec support: No
Design
Cable lock slot: Yes
Product colour: White
Placement: Ceiling, Wall
Recommended usage: Indoor
Cable lock slot type: Kensington
Power
Power consumption (max): 23.3 W
Power over Ethernet (PoE): Yes
Security
Security algorithms: WPA, WPA2, WMM
Operational conditions
Operating relative humidity (H-H): 5 - 93%
Storage relative humidity (H-H): 5 - 93%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 50 °C
Management features
Access point management: On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Weight & dimensions
Depth: 240 mm
Height: 57 mm
Weight: 1 kg
Width: 240 mm
Certification: UL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6 (ax) WPA, WPA2 and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, Wi-Fi Agile Multiband Wi-Fi CERTIFIED Location Bluetooth Special Interest Group (SIG)
Certificates
Compliance certificates: Electromagnetic Compatibility (EMC), ISED, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
Ports & interfaces
USB connector type: USB Type-A
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Antenna
Antenna features: Integrated antenna
Antenna type: Internal
Antennas quantity: 4
Antenna direction type: Omni-directional
Antenna gain level (max): 5.4 dBi
I/O ports: E0, E1: Ethernet port (RJ-45) Serial console interface (proprietary, micro-B USB physical jack) USB 2.0 host interface (Type A connector) Kensington security slot
Other features
Weight (imperial): 0.998 kg (2.2 lbs)
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: Electronic products should be recycled at specialist electronic waste collection facilities., Avoid direct contact with water., Do not expose to prolonged moisture.
