Power AC input frequency: 50 - 60 Hz AC input voltage: 200 - 240 V Power supply included: Yes Power consumption (typical): 19.5 W Power consumption (max): 29.3 W Power consumption note: 29.3W (maximum)
Security Access Control List (ACL): Yes SSH/SSL support: Yes IGMP snooping: Yes DHCP features: DHCP server
Operational conditions Operating relative humidity (H-H): 15 - 95% Storage temperature (T-T): -40 - 70 °C Operating temperature (T-T): 0 - 45 °C Heat dissipation: 100 BTU/h
Management features Quality of Service (QoS) support: Yes Web-based management: Yes Switch layer: L3 Traffic classification: Yes Switch type: Managed
Weight & dimensions Depth: 442.5 mm Height: 43.9 mm Width: 43.9 mm Weight: 2.41 kg
Network Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T, 10BASE-T VLAN support: Yes Auto MDI/MDI-X: Yes 10G support: No Full duplex: Yes Networking standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab Spanning tree protocol: Yes Link aggregation: Yes Routing entries: 10000 Rate limiting: Yes Flow control support: Yes Auto-sensing: Yes IP routing: Yes
Other features Weight (imperial): 2.41 kg (5.31 lbs) Latency: 1000 Mb Latency: < 3.8 µs Dimensions (W x D x H) (imperial): 43.9 x 442.5 x 200.2 mm (1.73 x 17.4 x 7.88") Memory and processor: Dual Core ARM Cortex A9 @ 1016 MHz 1 GB DDR3 SDRAM Packet buffer size: 12.38 MB 4.5 MB Ingress/7.875 MB Egress 4 GB eMMC
Logistics data Harmonized System (HS) code: 85176990
