Features
Spread spectrum method: DSSS, OFDMA, OFDM
Modulation: 16-QAM, BPSK, 256-QAM, CCK, 1024-QAM, 64-QAM, QPSK
MIMO type: Multi User MIMO
Networking standards: IEEE 802.11mc, IEEE 802.11ax
Maximum data transfer rate: 1774 Mbit/s
Ethernet LAN data rates: 1000 Mbit/s
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Bluetooth: Yes
Frequency band: 20/40 (2.4GHz), 20/40/80 (5GHz), peak data rate 1.49 Gbps, maximum data rate 1.78 Gbps
MIMO: Yes
Bluetooth version: 5.0
2.4 GHz: Yes
5 GHz: Yes
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
MDI / DMI-X automatic switchover: Yes
Design
Product colour: White
Placement: Pole, Wall
Recommended usage: Outdoor
Power
Power over Ethernet (PoE): Yes
Power consumption (max): 15.6 W
Security
Security algorithms: WPA2, WPA3
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating altitude: 0 - 3000 m
Operating temperature (T-T): -40 - 55 °C
Weight & dimensions
Height: 165 mm
Width: 165 mm
Depth: 130 mm
Weight: 1.03 kg
Certification: CB Scheme Safety, cTUVus UL2043 plenum rating Wi-Fi Alliance certified 802.11a/b/g/n/ Wi-Fi Alliance certified Wi-Fi 6 (802.11ax) Wi-Fi CERTIFIED ac (with wave 2 features) Wi-Fi CERTIFIED Location
Certificates
Compliance certificates: Low Voltage Directive (LVD), Federal Communications Commission (FCC), CE, Electromagnetic Compatibility (EMC), ISED
Ports & interfaces
USB connector type: USB Type-C
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna direction type: Omni-directional
Antenna features: Integrated antenna
Antenna type: Internal
Antenna gain level (max): 5.4 dBi
I/O ports: E0: 10/100/1000BASE-T (RJ-45) USB-C console interface
Other features
Weight (imperial): 1.03 kg (2.27 lbs)
Logistics data
Harmonized System (HS) code: 85176990
