Features
Networking standards: IEEE 802.11mc, IEEE 802.11ax
Trusted Platform Module (TPM): Yes
Ethernet LAN data rates: 5000 Mbit/s
Bluetooth version: 5.0
MIMO: Yes
2.4 GHz: Yes
Frequency band: 20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), 3.6 Gbps maximum peak data rate
Maximum data transfer rate (5 GHz): 1200 Mbit/s
Bluetooth: Yes
5 GHz: Yes
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate: 2400 Mbit/s
Bluetooth Low Energy (BLE): Yes
6 GHz: Yes
Maximum data transfer rate (6 GHz): 2400 Mbit/s
Design
Cable lock slot type: Kensington
Placement: Ceiling
Cable lock slot: Yes
Recommended usage: Indoor
Product colour: White
Power
Power over Ethernet (PoE): Yes
Security
Security algorithms: WPA3, WPA2, WPA, WPA3-SAE
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 10 - 100%
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -25 - 55 °C
Weight & dimensions
Width: 201 mm
Depth: 183 mm
Height: 51 mm
Weight: 720 g
Packaging data
Package weight: 800 g
Package depth: 194 mm
Package height: 66 mm
Package width: 212 mm
Certification: UL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2, and WPA3 Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi agile multiband Wi-Fi CERTIFIED Location™ Bluetooth SIG Ethernet Alliance (PoE, PD device, class 4)
Certificates
Compliance certificates: Federal Communications Commission (FCC), Low Voltage Directive (LVD), ISED, CE
Ports & interfaces
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Antenna
Antenna direction type: Omni-directional
Antenna gain level (max): 6 dBi
Antenna type: Internal
I/O ports: E0: Ethernet wired network ports (RJ-45) USB 2.0 host interface (Type A connector) Serial console interface (proprietary, micro-B USB physical jack) Kensington security slot
Other features
Weight (imperial): 0.721 kg (1.59 lbs)
