Features
Bluetooth version: 5.0
MIMO: Yes
Modulation: QPSK, 256-QAM, 16-QAM, BPSK, 64-QAM, CCK, 1024-QAM
Frequency band: 20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.9 Gbps
Ethernet LAN data rates: 5000 Mbit/s, 2500
GLONASS: Yes
Networking standards: IEEE 802.11ax, IEEE 802.11mc
5 GHz: Yes
Maximum data transfer rate: 2400 Mbit/s
GPS (satellite): Yes
2.4 GHz: Yes
Bluetooth: Yes
6 GHz: Yes
Design
Product colour: White
Recommended usage: Indoor
Placement: Ceiling
Power
Power over Ethernet (PoE): Yes
Security
Security algorithms: WPA2, WPA, WPA3
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -25 - 55 °C
Storage relative humidity (H-H): 10 - 100%
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Width: 220 mm
Depth: 220 mm
Height: 51 mm
Weight: 1.3 kg
Certification: UL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2 and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE, PD device, class 5)
Certificates
Compliance certificates: CE, Electromagnetic Compatibility (EMC), ISED, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
Ports & interfaces
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Antenna
Antenna features: Integrated antenna
Antenna gain level (max): 7 dBi
Antenna direction type: Omni-directional
Antenna type: Internal
I/O ports: E0, E1: Two Ethernet wired network ports (RJ-45); Auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX; 2.5Gbps speed complies with NBase-T and 802.3bz specifications; POE-PD: 48Vdc (nominal) 802.3af/at/bt POE (class 3 or higher); 802.3az Energy Efficient Ethernet (EEE)
Other features
Weight (imperial): 1.3 kg (2.86 lbs)
Safety warning
Warnings: Avoid direct contact with water., Electronic products should be recycled at specialist electronic waste collection facilities., Do not expose to prolonged moisture.
