Design
Rack mounting: Yes
Form factor: 1U
Product colour: Black
Power
Power source: AC
AC input frequency: 50/60 Hz
AC input voltage: 200 - 240 V
Power consumption (max): 439 W
Power consumption note: Max. Power (w/o PoE): 41.0W Max. Power (w/ PoE): 439W
Security
DHCP features: DHCP snooping, DHCP client, DHCP relay, DHCP server
Access Control List (ACL): Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 45 °C
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Switch layer: L2/L3
Configuring Location Settings (CLI): Yes
Switch type: Managed
Cloud-managed: Yes
Weight & dimensions
Height: 43.9 mm
Width: 442.5 mm
Depth: 304.4 mm
Weight: 4.39 kg
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ab, IEEE 802.3at, IEEE 802.3af, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1w, IEEE 802.1D
10G support: No
Flow control support: Yes
Performance
Processor model: ARM Cortex-A9
Built-in processor: Yes
Internal memory: 4096 MB
Flash memory: 16000 MB
Memory type: DDR3-SDRAM
Processor manufacturer: ARM
Processor frequency: 1016 MHz
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 48
USB 2.0 ports quantity: 1
SFP module slots quantity: 4
Console port: USB
I/O ports: 48 x 10/100/1000BASE-T Class 4 PoE ports 4 x 1 G SFP ports Supports PoE Standards IEEE 802.3af, 802.3at 1 x USB-C console port 1 x USB Type-A host port
Other features
Latency: 1 Gbps: 1.9 μSec
Memory and processor: CPU: Dual-core Arm Cortex-A9 @ 1016 MHz Memory: 4 GB DDR3 Flash: 16 GB eMMC
Data transmission
MAC address table: 8192 entries
Static route: Yes
Switching capacity: 104 Gbit/s
Throughput: 77.3 Mpps
Latency (1 Gbps): 1.9 µs
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE): Yes
Multicast features
Multicast support: Yes
