Design
Product colour: Black
Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Airflow direction: Side-to-side airflow
Power
AC input frequency: 50 - 60 Hz
Power consumption (max): 32.7 W
Power source: AC
Power supply included: Yes
AC input voltage: 200 - 240 V
Power consumption note: Max. Power (w/o PoE): 32.7W Max. Power (w/ PoE): 455W
Security
Access Control List (ACL): Yes
IGMP snooping: Yes
Authentication: MAC-based authentication
DHCP features: DHCP client
Authentication type: RADIUS, TACACS+
Operational conditions
Storage relative humidity (H-H): 15 - 90%
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 15 - 95%
Operating temperature (T-T): 0 - 45 °C
Management features
Switch type: Managed
Quality of Service (QoS) support: Yes
Switch layer: L3
Weight & dimensions
Height: 268 mm
Width: 44 mm
Weight: 4.2 kg
Depth: 442 mm
Network
Networking standards: IEEE 802.3af, IEEE 802.3, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3at, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3az, IEEE 802.1w
VLAN support: Yes
10G support: Yes
Flow control support: Yes
Port mirroring: Yes
Spanning tree protocol: Yes
Link aggregation: Yes
Performance
Virtual stacking (units): 16
Flash memory: 16 MB
Internal memory: 4096 MB
Processor model: ARM Cortex-A9
Built-in processor: Yes
Processor frequency: 1016 MHz
Memory type: DDR3-SDRAM
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
SFP+ module slots quantity: 4
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Console port: USB
I/O ports: 24 x 10/100/1000BASE-T ports 4 x 1G/10G SFP ports Supports PoE standards IEEE 802.3af, 802.3at 1 x USB-C console port 1 x USB Type-A host port
Other features
Weight (imperial): 4.19 kg (9.24 lbs)
Fan: Fixed fans
Memory and processor: Dual Core ARM Cortex A9 @ 1016 Mhz 4 GB DDR3, maximum, depending on model 16 GB eMMC
Latency: 1 Gbps: 1.5 μSec , 10 Gbps: 1.8 μSec
Dimensions (W x D x H) (imperial): 43.9 x 442 x 268.2 mm (1.73 x 17.4 x 10.6")
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Throughput: 95.2 Mpps
Latency (1 Gbps): 1.5 µs
MAC address table: 8192 entries
Latency (10 Gbps): 1.8 µs
Switching capacity: 128 Gbit/s
Packet buffer memory: 12.38 MB
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 370 W
Multicast features
Multicast support: Yes
Safety warning
Warnings: The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Ensure the unit is adequately ventilated during operation., Do not open the case or try to repair it yourself.
