Design
Form factor: 1U
Rack mounting: Yes
Product colour: White
Stackable: Yes
Power
Power source: AC
AC input frequency: 50 - 60 Hz
Power supply included: Yes
AC input voltage: 200 - 240 V
Power consumption (max): 160 W
Power consumption note: Maximum: 100-127V: 130W 200-220V: 160W Idle: 100-127V: 60W 200-220V: 80W
Security
IGMP snooping: Yes
DHCP features: DHCP snooping
SSH/SSL support: Yes
Access Control List (ACL): Yes
Authentication: Port-based authentication
Authentication type: RADIUS
Operational conditions
Storage relative humidity (H-H): 15 - 90%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 15 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating altitude: 0 - 3000 m
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Cloud-managed: Yes
Switch type: Managed
Switch layer: L2+
System event log: Yes
Weight & dimensions
Width: 350.5 mm
Height: 44 mm
Weight: 4.3 kg
Depth: 442.5 mm
Network
Networking standards: IEEE 802.3u, IEEE 802.1D, IEEE 802.3z, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3ad, IEEE 802.1s, IEEE 802.3az, IEEE 802.1ab, IEEE 802.1x, IEEE 802.1AX, IEEE 802.3ab, IEEE 802.1p
VLAN support: Yes
Auto MDI/MDI-X: Yes
Full duplex: Yes
10G support: Yes
Port mirroring: Yes
Rate limiting: Yes
Flow control support: Yes
Auto-sensing: Yes
Spanning tree protocol: Yes
Link aggregation: Yes
Performance
Processor model: ARM Cortex-A9
Flash memory: 512 MB
Memory type: DDR3-SDRAM
Internal memory: 1024 MB
Processor frequency: 2000 MHz
Built-in processor: Yes
Physical stacking (units): 4
Protocols
IPv4 FIB entries: 512
IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL)
IPv6 FIB entries: 512
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 12
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
SFP+ module slots quantity: 4
I/O ports: 12 RJ-45 autosensing 1000/10 GBASE-T ports (IEEE 802.3ab Type 1000 BASE-T, IEEE 802.an 10 GBASE-T); Duplex: 100 BASE-TX: half or full; 1000 BASE-T: full only 10 GBASE-T: full only 4 SFP+ 10GbE ports
Other features
Weight (imperial): 4.35 kg (9.6 lbs)
Performance management: HPE Networking Instant On Cloud; Web browser; SNMP Manager
Memory and processor: Single-Core ARM v7 Cortex-A9 @800 MHz; 1 GB DDR3; 512 MB NAND flash; Packet buffer size: 1.5 MB
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Packet buffer memory: 1.5 MB
MAC address table: 16000 entries
Jumbo frames support: Yes
Switching capacity: 320 Gbit/s
Throughput: 238 Mpps
Latency (10 Gbps): 1.1 µs
Latency (1 Gbps): 4.2 µs
Latency (10-100 Mbps): 7.4 µs
Jumbo frames: 9216
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
