Design
Form factor: 1U
Product colour: White
Rack mounting: Yes
Stackable: Yes
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 200 - 240 V
Power consumption (max): 480 W
Power source: AC
Power supply included: Yes
Power consumption note: Maximum: 100-127V: 500W 200-220V: 480W Idle: 100-127V: 40W 200-220V: 80W
Security
Authentication type: RADIUS
SSH/SSL support: Yes
Authentication: Port-based authentication
IGMP snooping: Yes
Access Control List (ACL): Yes
DHCP features: DHCP snooping
Operational conditions
Operating relative humidity (H-H): 15 - 95%
Storage relative humidity (H-H): 15 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating altitude: 0 - 3000 m
Management features
Web-based management: Yes
Quality of Service (QoS) support: Yes
Cloud-managed: Yes
ARP inspection: Yes
Switch type: Managed
Switch layer: L2+
System event log: Yes
Weight & dimensions
Height: 44 mm
Depth: 442.5 mm
Weight: 4.7 kg
Width: 350.5 mm
Network
Networking standards: IEEE 802.1ab, IEEE 802.1x, IEEE 802.3bt, IEEE 802.1AX, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.3az, IEEE 802.3at, IEEE 802.3u, IEEE 802.1D, IEEE 802.3z
Auto MDI/MDI-X: Yes
VLAN support: Yes
Full duplex: Yes
Link aggregation: Yes
Flow control support: Yes
10G support: Yes
Spanning tree protocol: Yes
Port mirroring: Yes
Auto-sensing: Yes
Rate limiting: Yes
Performance
Flash memory: 512 MB
Processor model: ARM Cortex-A9
Processor frequency: 800 MHz
Built-in processor: Yes
Internal memory: 1024 MB
Memory type: DDR3-SDRAM
Physical stacking (units): 4
Protocols
IPv6 FIB entries: 32
IPv4 FIB entries: 32
IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL)
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
10G Ethernet (copper) ports quantity: 2
SFP+ module slots quantity: 2
I/O ports: 24 RJ-45 autosensing 10/100/1000 BASE-T ports with 4 ports of IEEE 802.af/at/bt CL6 PoE and 20 ports of IEEE 802.af/at CL4 PoE (IEEE 802.3u Type 100 BASE-TX, IEEE 802.3ab Type 1000 BASE-T, IEEE 802.an 10 GBASE-T); Duplex: 100 BASE-TX: half or full; 1000 BASE-T: full only 10 GBASE-T: full only 2 SFP+ 10 GbE ports 2 RJ-45 autosensing 100/1000/10 GBASE-T ports
Other features
Weight (imperial): 4.72 kg (10.4 lbs)
Performance management: HPE Networking Instant On Cloud; Web browser; SNMP Manager
Memory and processor: Single-Core ARM v7 Cortex-A9 @800 MHz; 1 GB DDR3; 512 MB NAND flash; Packet buffer size: 1.5 MB
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 128 Gbit/s
Jumbo frames: 9216
Jumbo frames support: Yes
Packet buffer memory: 1.5 MB
Latency (10 Gbps): 1.1 µs
MAC address table: 16000 entries
Latency (1 Gbps): 2.2 µs
Latency (10-100 Mbps): 4.4 µs
Throughput: 95 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 370 W
Multicast features
Multicast support: Yes
Safety warning
Warnings: Do not open the case or try to repair it yourself., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Ensure the unit is adequately ventilated during operation.
