Design
Stackable: Yes
Rack mounting: Yes
Product colour: White
Form factor: 1U
Power
Power consumption (max): 80 W
AC input frequency: 50 - 60 Hz
Power supply included: Yes
AC input voltage: 200 - 240 V
Power consumption note: Maximum: 100-127V: 60W 200-220V: 80W Idle: 100-127V: 30W 200-220V: 40W
Security
Access Control List (ACL): Yes
Authentication: Port-based authentication
DHCP features: DHCP snooping
IGMP snooping: Yes
Authentication type: RADIUS
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 15 - 95%
Storage relative humidity (H-H): 15 - 90%
Operating altitude: 0 - 3000 m
Storage temperature (T-T): -40 - 70 °C
Management features
Switch layer: L2+
Switch type: Managed
System event log: Yes
Web-based management: Yes
Quality of Service (QoS) support: Yes
Cloud-managed: Yes
Weight & dimensions
Depth: 442.5 mm
Weight: 3.9 kg
Height: 44 mm
Width: 350.5 mm
Network
Flow control support: Yes
Full duplex: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.1AX, IEEE 802.3u, IEEE 802.1D, IEEE 802.3z, IEEE 802.3az, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1ab, IEEE 802.1w
10G support: Yes
VLAN support: Yes
Auto MDI/MDI-X: Yes
Port mirroring: Yes
Spanning tree protocol: Yes
Link aggregation: Yes
Auto-sensing: Yes
Performance
Internal memory: 1024 MB
Flash memory: 512 MB
Processor model: ARM Cortex-A9
Built-in processor: Yes
Processor frequency: 800 MHz
Memory type: DDR3-SDRAM
Physical stacking (units): 4
Protocols
IPv6 FIB entries: 32
IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL)
IPv4 FIB entries: 32
Ports & interfaces
SFP+ module slots quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
10G Ethernet (copper) ports quantity: 2
I/O ports: 24 RJ-45 autosensing 10/100/1000 BASE-T ports (IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.an 10GBASE-T); Duplex: 100 BASE-TX: half or full; 1000 BASE-T: full only 10 GBASE-T: full only 2 SFP+ 10 GbE ports 2 RJ-45 autosensing 100/1000/10 GBASE-T ports
Other features
Weight (imperial): 3.95 kg (8.7 lbs)
Memory and processor: Single-Core ARM v7 Cortex-A9 @800 MHz; 1 GB DDR3; 512 MB NAND flash; Packet buffer size: 1.5 MB
Performance management: HPE Networking Instant On Cloud; Web browser; SNMP Manager
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 128 Gbit/s
Latency (1 Gbps): 2.2 µs
Latency (10-100 Mbps): 4.4 µs
Packet buffer memory: 1.5 MB
MAC address table: 16000 entries
Jumbo frames: 9216
Throughput: 95 Mpps
Jumbo frames support: Yes
Latency (10 Gbps): 1.1 µs
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Safety warning
Warnings: The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Ensure the unit is adequately ventilated during operation., Do not open the case or try to repair it yourself.
