Design
Rack mounting: Yes
Form factor: 1U
Power
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power supply included: Yes
Power consumption (max): 7.8 W
Power source: AC
Power consumption note: Maximum: 100-127V: 19.1W 200-220V: 19W: Idle: 100-127V: 7.6W 200-220V: 7.8W
Security
SSH/SSL support: Yes
DHCP features: DHCP client
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 15 - 95%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 15 - 95%
Management features
Web-based management: Yes
Switch layer: L2
Quality of Service (QoS) support: Yes
Switch type: Managed
System event log: Yes
Cloud-managed: Yes
Weight & dimensions
Weight: 2.49 kg
Depth: 443 mm
Height: 43.9 mm
Width: 215.9 mm
Network
Networking standards: IEEE 802.3ad, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1D, IEEE 802.3z, IEEE 802.1w, IEEE 802.3ac
Port mirroring: Yes
10G support: No
VLAN support: Yes
Full duplex: Yes
Auto MDI/MDI-X: Yes
Link aggregation: Yes
Flow control support: Yes
Spanning tree protocol: Yes
Auto-sensing: Yes
Performance
Flash memory: 256 MB
Built-in processor: Yes
Processor frequency: 800 MHz
Memory type: SDRAM
Internal memory: 512 MB
Processor model: ARM Cortex-A9
Fanless: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
SFP module slots quantity: 2
I/O ports: 24 RJ-45 10/100/1000 ports, 2 SFP 1GbE ports
Other features
Weight (imperial): 2.49 kg (5.5 lbs)
Performance management: HPE Networking Instant On Cloud; Web browser; SNMP Manager
Memory and processor: ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 16000 entries
Jumbo frames support: Yes
Jumbo frames: 9216
Latency (1 Gbps): 2.8 µs
Latency (10-100 Mbps): 5.2 µs
Packet buffer memory: 1.5 MB
Switching capacity: 52 Gbit/s
Throughput: 38.68 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
