Design
Form factor: 1U
Rack mounting: Yes
Power
Power consumption (max): 462.5 W
Power supply included: Yes
AC input frequency: 50 - 60 Hz
AC input voltage: 100 - 240 V
Power source: AC
Power consumption note: Maximum: 100-127V: 462.5W 200-220V: 452.5W; Idle: 100-127V: 25.8W 200-220V: 25.4W
Security
IGMP snooping: Yes
SSH/SSL support: Yes
DHCP features: DHCP client
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Management features
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch type: Managed
System event log: Yes
Switch layer: L2
Cloud-managed: Yes
Weight & dimensions
Weight: 4.94 kg
Width: 351 mm
Height: 43.9 mm
Depth: 443 mm
Network
VLAN support: Yes
Networking standards: IEEE 802.3u, IEEE 802.3at, IEEE 802.1ab, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.3ac, IEEE 802.1D, IEEE 802.3z
Auto MDI/MDI-X: Yes
Full duplex: Yes
Auto-sensing: Yes
Port mirroring: Yes
Flow control support: Yes
10G support: No
Spanning tree protocol: Yes
Link aggregation: Yes
Performance
Processor frequency: 800 MHz
Flash memory: 256 MB
Built-in processor: Yes
Processor model: ARM Cortex-A9
Internal memory: 512 MB
Memory type: SDRAM
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 48
SFP module slots quantity: 4
I/O ports: 48 RJ-45 10/100/1000 Class 4 PoE ports, 4 SFP 1GbE ports
Other features
Weight (imperial): 4.94 kg (10.9 lbs)
Performance management: HPE Networking Instant On Cloud; Web browser; SNMP Manager
Memory and processor: ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB
Dimensions (W x D x H) (imperial): 351 x 443 x 43.9 mm (13.8 x 17.4 x 1.73")
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 104 Gbit/s
Jumbo frames support: Yes
Latency (10-100 Mbps): 5.2 µs
MAC address table: 16000 entries
Latency (1 Gbps): 2.8 µs
Packet buffer memory: 1.5 MB
Throughput: 77.37 Mpps
Jumbo frames: 9216
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 370 W
Safety warning
Warnings: Avoid contact of the device with liquid., Make sure the ventilation of the equipment is not blocked., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Follow the safety guidelines for electrical current., Ensure the unit is adequately ventilated during operation., Do not open the case or try to repair it yourself.
