Power Power supply: 800 W Redundant power supply (RPS) support: Yes Power supply type: 1x HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit Number of main power supplies: 1
Weight & dimensions Height: 368.3 mm Depth: 475 mm Width: 175.3 mm
Performance Trusted Platform Module (TPM): Yes Trusted Platform Module (TPM) version: 2.0 Remote administration: iLO 6 ASIC Compatible operating systems: Microsoft Windows Server
VMware ESXi
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Canonical Ubuntu
Software Operating system installed: No
Storage Maximum storage capacity: 61.44 TB SSD interface: SATA III Number of SSDs installed: 2 RAID support: Yes RAID levels: 1, 0, 10, 5 SSD capacity: 480 GB Total storage capacity: 960 GB Supported RAID controllers: Embedded Intel VROC SATA (formerly known as Intel RSTe) Number of HDDs installed: 2 Optical drive type: No Hot-Plug support: Yes Number of SSDs supported: 8 Supported SSD sizes: 2.5" Expansion slots: 4, for detailed descriptions refer to the QuickSpecs
Ports & interfaces VGA (D-Sub) ports quantity: 1 Ethernet LAN (RJ-45) ports: 4 DisplayPorts quantity: 1 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5 USB 2.0 ports quantity: 1
Other features Number of processors supported: 1 Standard fans: 1x Standard Fan Storage drive type: 2x HPE 480GB SATA 6G Read Intensive SFF BC Multi Vendor SSD Warranty period: 3 year(s)
