Power Number of redundant power supplies installed: 2 Redundant power supply (RPS) support: Yes Power supply type: 2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit Number of main power supplies: 2 Power supply: 1000 W
Weight & dimensions Height: 462 mm Depth: 712 mm Width: 174 mm
Performance Trusted Platform Module (TPM): Yes Trusted Platform Module (TPM) version: 2.0 Remote administration: iLO 6 ASIC Compatible operating systems: Microsoft Windows Server
VMware ESXi
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Canonical Ubuntu
Oracle Linux and Oracle VM
Citrix
Software Operating system installed: No
Storage SSD size: 2.5" Supported SSD sizes: 2.5" Number of SSDs supported: 8 RAID levels: 10, 5, 6, 60, 0, 1, 50 Number of HDDs installed: 2 Supported RAID controllers: HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller Optical drive type: No SSD capacity: 960 GB SSD interface: SATA III Hot-Plug support: Yes Maximum storage capacity: 368.64 TB RAID support: Yes Total storage capacity: 1.92 TB Number of SSDs installed: 2 Expansion slots: Default with 4 x8 PCIe 5.0 slots. Refer to the QuickSpecs for more detail.
Ports & interfaces VGA (D-Sub) ports quantity: 1 Ethernet LAN (RJ-45) ports: 4 DisplayPorts quantity: 1 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Other features Number of processors supported: 1 Storage drive type: 2x HPE 960GB SATA 6G Mixed Use SFF BC Multi Vendor SSD Standard fans: 3x Standard Fans
