Design Cooling type: Active Fan location: Side Fan diameter: 12 cm Product colour: Silver Number of fans: 1 fan(s)
Power Combined power (+3.3V): 130 W Input current: 3 A AC input voltage: 230 V Power consumption (max): 400 W Total power: 400 W AC input frequency: 50 - 60 Hz Power protection features: Overload, Short circuit, Over voltage, Under voltage, Over current Max output current (+5V): 22 A Power Factor Correction (PFC) type: Passive Combined power (+5V): 130 W Combined power (+5Vsb): 12.5 W Max output current (+5Vsb): 2.5 A Max output current (+12V2): 12 A Max output current (+3.3V): 15 A Max output current (-12V): 0.3 A Combined power (-12V): 3.6 W Max output current (+12V1): 10 A
Weight & dimensions Depth: 85 mm Width: 140 mm Height: 150 mm Certification: CE
Performance ATX version: 2.2 Safety: UVP / OVP / SCP / OPP / OCP / OTP Noise level: 20 dB Power supply unit (PSU) form factor: ATX
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 Motherboard power connector: 20+4 pin ATX ATX power connector (20+4 pin): Yes Number of SATA power connectors: 2 Cabling type: Non-Modular
