Technical details
Playback media: Y
Compliance certificates: CB, EAC, TÜV mark, REACH, UKCA, RoHS, CE, WEEE
Sustainability certificates: ErP
Features
Wall mountable: Yes
Design
Product design: Digital A-board
Product colour: Black
Anti-glare screen: Yes
Orientation: Horizontal/Vertical
Bezel width (side): 1.33 cm
Bezel width (top): 1.33 cm
VESA mounting: Yes
Bezel width (bottom): 1.53 cm
Placement supported: Indoor
Panel mounting interface: 300 x 400 mm
Bezel colour: Black
Power
AC input frequency: 50/60 Hz
Power consumption (off): 0.3 W
AC input voltage: 100 - 240 V
Power consumption (typical): 55 W
Energy consumption (SDR) per 1000 hours: 54.9 kWh
Energy efficiency class (SDR): E
Power consumption (standby): 0.5 W
Energy efficiency class (HDR): Not available
Energy efficiency scale: A to G
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Weight: 17.6 kg
Depth: 38.6 mm
Display height: 712.5 mm
Display depth: 38.6 mm
Height: 712.5 mm
Width: 1239.7 mm
Display weight: 17.6 kg
Display width: 1239.7 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
HDCP: Yes
On Screen Display (OSD) languages: Japanese, Spanish, Danish, German, Italian, Dutch, Swedish, Polish, English, Norwegian, Finnish, Russian, Czech, Traditional Chinese, French
Operating hours (hours/days): 24/7
Purpose: Universal
Number of OSD languages: 15
HDCP version: 1.4/2.2
Mean time between failures (MTBF): 50000 h
On Screen Display (OSD): Yes
Packaging data
Package width: 1390 mm
Package depth: 136 mm
Package weight: 22.9 kg
Package height: 850 mm
Packaging content
Cables included: HDMI, RS-232, AC
Mounting kit: Yes
Batteries included: Yes
Remote control included: Yes
Display
Viewing angle, horizontal: 178°
Response time: 6.5 ms
HD type: 4K Ultra HD
Display resolution: 3840 x 2160 pixels
Native aspect ratio: 16:9
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Pixel pitch: 0.315 x 0.315 mm
Display number of colours: 1.07 billion colours
Display diagonal: 138.7 cm (54.6")
Display diagonal (metric): 139 cm
Surface hardness: 3H
Panel type: VA
Active display area (W x H): 1209.6 x 680.4 mm
Display brightness: 500 cd/m²
Touchscreen: No
Contrast ratio (typical): 4000:1
Native refresh rate: 60 Hz
Display technology: LED
Haze rate: 25%
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 20 W
Ports & interfaces
HDMI version: 2.0
Ethernet LAN (RJ-45) ports: 1
DVI port: No
HDMI ports quantity: 3
RS-232 interface: Yes
RS-232C: Yes
USB port: Yes
USB ports quantity: 2
PC Audio in: Yes
USB version: 2.0
Other features
Quick start guide: Yes
Power supply type: Internal
Computer system
Processor family: ARM Cortex
Processor model: A53
Internal memory: 2 GB
Processor manufacturer: ARM
Processor cores: 4
On-board graphics card model: ARM Mali-G52
Operating system installed: Android 11
Processor architecture: ARM Cortex-A53
Computer system: No
Internal storage capacity: 16 GB
Built-in processor: Yes
