Design
Product colour: Black
Front bezel colour: Black
Power
Power consumption (typical): 24.4 W
Power consumption (off): 0.32 W
AC adapter output voltage: 12 V
European Product Registry for Energy Labelling (EPREL) code: 378595
Power supply type: External
Energy efficiency class (SDR): F
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 22 kWh
Power consumption (standby): 1.06 W
Operational conditions
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Height (with stand): 347 mm
Width (with stand): 575 mm
Depth (with stand): 42.5 mm
Weight (with stand): 5.8 kg
Weight (without stand): 5.8 kg
Depth (without stand): 42.5 mm
Height (without stand): 347 mm
Width (without stand): 575 mm
Performance
NVIDIA G-SYNC: No
OmniTapps Multitouch compatibility: No
AMD FreeSync: No
Packaging content
Cables included: DisplayPort, HDMI, USB, AC
Quick start guide: Yes
Display
Response time: 16 ms
Screen shape: Flat
Horizontal scan range: 31.4 - 82 kHz
Display resolution: 1920 x 1080 pixels
Display brightness (typical): 350 cd/m²
Viewing angle, horizontal: 178°
Aspect ratio: 16:9
Vertical scan range: 56 - 75 Hz
HD type: Full HD
Native aspect ratio: 16:9
Viewing angle, vertical: 178°
Display diagonal: 60.5 cm (23.8")
Display number of colours: 16.78 million colours
Pixel pitch: 0.2745 x 0.2745 mm
Touchscreen: Yes
Display technology: LED
Panel type: VA
Touch technology: Multi-touch
Viewable size, vertical: 29.6 cm
Contrast ratio (typical): 3000:1
Display brightness: 315 cd/m²
Separate H/V sync: Yes
Touchscreen technology: Projected capacitive system
Display diagonal (metric): 60.5 cm
Surface hardness: 7H
Viewable size, horizontal: 52.7 cm
Touchscreen type: Multi-user
Number of simultaneous touchpoints: 10
Multimedia
Built-in microphone: No
Built-in camera: No
Ergonomics
Panel mounting interface: 100 x 100 mm
On Screen Display (OSD) languages: English, Japanese, Spanish, German, Italian, Traditional Chinese, French
Wall mountable: Yes
On Screen Display (OSD): Yes
VESA mounting: Yes
Plug and Play: Yes
Number of OSD languages: 7
Ports & interfaces
DisplayPorts quantity: 1
HDCP: Yes
HDMI ports quantity: 1
HDMI: Yes
USB Touch port: Yes
VGA (D-Sub) ports quantity: 1
Audio output: 1
Packaging content: AC adapter, Touch Panel Driver Disk (CD-ROM), external control pad
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CB, CE, TÜV-Bauart, CU, cULus
Other features
Width: 575 mm
AC adapter included: Yes
Weight: 5.8 kg
Full HD: Yes
Compliance certificates: RoHS, WEEE, REACH, CB, cULus, CE
Brightness: 315 cd/m²
Depth: 42.5 mm
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Active display area (W x H): 527.04 x 296.46 mm
Display viewable area (HxV): 527.04 x 296.46 mm
Height: 347 mm
Glass protection: Yes
Touch method: stylus, finger, glove (latex)
International Protection (IP) code: IP65
Placement supported: Horizontal/Vertical
Logistics data
Harmonized System (HS) code: 85285210
Sustainability
Sustainability certificates: ErP
