Technical details
Compliance certificates: UKCA, RoHS, CE, REACH, WEEE, TÜV mark
Playback media: Y
Sustainability certificates: ErP
Audio in (mini jack): Yes
Design
Bezel width (side): 1.48 cm
Bezel colour: Black
Bezel width (top): 1.4 cm
Orientation: Horizontal/Vertical
Panel mounting interface: 200 x 200 mm
Placement supported: Indoor
Bezel width (bottom): 7.5 cm
VESA mounting: Yes
Product design: Kiosk design
Product colour: Black
Power
Energy consumption (SDR) per 1000 hours: 39.2 kWh
Energy efficiency class (SDR): G
Energy efficiency scale: A to G
Energy efficiency class (HDR): Not available
Power consumption (standby): 0.4 W
Power consumption (typical): 39 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (off): 0.3 W
Operational conditions
Operating relative humidity (H-H): -20 - 60%
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Display width: 725.5 mm
Display depth: 54 mm
Height: 422 mm
Display weight: 5.1 kg
Width: 725.5 mm
Display height: 422 mm
Depth: 54 mm
Weight: 5.1 kg
Network
Ethernet LAN: Yes
Wi-Fi: No
Performance
Operating hours (hours/days): 24/7
Mean time between failures (MTBF): 50000 h
HDCP version: 2.2
On Screen Display (OSD) languages: Japanese, German, Italian, Dutch, Russian, English, French, Spanish
Number of OSD languages: 8
Purpose: Commercial
On Screen Display (OSD): Yes
HDCP: Yes
Packaging data
Package height: 554 mm
Package width: 824 mm
Package depth: 119 mm
Packaging content
Remote control included: Yes
Cables included: AC, HDMI, RS-232
Display
Active display area (W x H): 698.4 x 392.9 mm
Haze rate: 1%
Display technology: LED
Contrast ratio (typical): 1200:1
Display brightness: 350 cd/m²
Touchscreen: No
Native refresh rate: 60 Hz
Display diagonal (metric): 80 cm
Panel type: IPS
Viewing angle, vertical: 178°
Native aspect ratio: 16:9
Horizontal scan range: 30 - 80 kHz
Response time: 8 ms
Display diagonal: 80 cm (31.5")
Display resolution: 1920 x 1080 pixels
Display number of colours: 16.7 million colours
Pixel pitch: 0.364 x 0.364 mm
Viewing angle, horizontal: 178°
HD type: Full HD
Audio
Number of built-in speakers: 2
RMS rated power: 20 W
Built-in speaker(s): Yes
Ports & interfaces
Number of speaker outputs: 1
Remote (IR) output: 1
Remote (IR) input: 1
VGA (D-Sub) input ports: 1
USB port: Yes
DVI port: No
Audio (L/R) in: 1
RS-232C: Yes
USB ports quantity: 1
USB version: 2.0
HDMI ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
Other features
Cable management: Yes
Power supply type: Internal
Quick start guide: Yes
Computer system
Built-in processor: No
Computer system: No
