Technical details
Playback media: Y
Sustainability certificates: ErP
Compliance certificates: UKCA, RoHS, CE, CB, EAC, WEEE, REACH, TÜV mark
Design
Product colour: Black
Product design: Digital A-board
VESA mounting: Yes
Panel mounting interface: 150 x 200 mm
Bezel width (bottom): 9 mm
Anti-glare screen: Yes
Bezel width (side): 9 mm
Bezel width (top): 9 mm
Bezel colour: Black
Orientation: Horizontal/Vertical
Placement supported: Indoor
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 40 W
Power consumption (off): 0.3 W
AC input frequency: 50/60 Hz
Energy efficiency class (SDR): G
Power consumption (standby): 0.5 W
Energy efficiency class (HDR): Not available
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Width: 724.6 mm
Weight: 5.4 kg
Height: 419.8 mm
Depth: 40 mm
Display weight: 5.4 kg
Display depth: 40 mm
Display height: 419.8 mm
Display width: 724.6 mm
Network
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Performance
Purpose: Universal
On Screen Display (OSD): Yes
HDCP: Yes
On Screen Display (OSD) languages: English, Norwegian, German, Italian, Dutch, Japanese, Swedish, Polish, Finnish, Russian, Czech, Danish, Spanish, Traditional Chinese, French
Mean time between failures (MTBF): 50000 h
Operating hours (hours/days): 24/7
HDCP version: 1.4/2.2
Packaging data
Package width: 795 mm
Package height: 520 mm
Package depth: 115 mm
Package weight: 7.3 kg
Packaging content
Mounting kit: Yes
Cables included: RS-232, HDMI, AC
Batteries included: Yes
Remote control included: Yes
Display
Native aspect ratio: 16:9
Display diagonal: 80 cm (31.5")
Viewing angle, horizontal: 178°
HD type: Full HD
Display resolution: 1920 x 1080 pixels
Touchscreen: No
Response time: 8 ms
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Pixel pitch: 0.364 x 0.364 mm
Display number of colours: 16.7 million colours
Panel type: VA
Display brightness: 500 cd/m²
Display technology: LED
Surface hardness: 3H
Display diagonal (metric): 80 cm
Native refresh rate: 60 Hz
Active display area (W x H): 698.4 x 392.85 mm
Contrast ratio (typical): 4000:1
Haze rate: 25%
Audio
RMS rated power: 20 W
Number of built-in speakers: 2
Built-in speaker(s): Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DVI port: No
USB port: Yes
HDMI ports quantity: 3
HDMI version: 2.0
USB version: 2.0
Audio (L/R) in: 1
RS-232C: Yes
USB ports quantity: 2
Audio (L/R) out: 1
Remote (IR) input: 1
Other features
Quick start guide: Yes
Power supply type: Internal
Computer system
Processor cores: 4
Processor model: A53
Processor manufacturer: ARM
Operating system installed: Android 11
Processor family: ARM Cortex
Built-in processor: Yes
Internal memory: 2 GB
On-board graphics card model: ARM Mali-G52
Computer system: No
Processor architecture: ARM Cortex-A53
Internal storage capacity: 16 GB
