Technical details
Compliance certificates: RoHS, CE, UKCA, REACH, WEEE, TÜV mark
Playback media: Y
Sustainability certificates: ErP
Design
Bezel colour: Black
Placement supported: Indoor
Panel mounting interface: 200 x 200 mm
VESA mounting: Yes
Product design: Digital signage flat panel
Product colour: Black
Orientation: Horizontal/Vertical
Bezel width (bottom): 1.19 cm
Bezel width (side): 1.19 cm
Anti-glare screen: Yes
Bezel width (top): 1.19 cm
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 46 W
Power consumption (standby): 0.4 W
Power consumption (off): 0.3 W
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): G
Energy consumption (SDR) per 1000 hours: 45.7 kWh
Energy efficiency scale: A to G
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 5.2 kg
Depth: 54 mm
Width: 725.5 mm
Height: 421.8 mm
Display depth: 54 mm
Display height: 421.8 mm
Display weight: 5.2 kg
Display width: 725.5 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Performance
HDCP: Yes
Purpose: Universal
On Screen Display (OSD): Yes
Operating hours (hours/days): 24/7
Number of OSD languages: 11
Mean time between failures (MTBF): 44000 h
On Screen Display (OSD) languages: Spanish, Japanese, German, Italian, Danish, Dutch, Swedish, Polish, Russian, Czech, English, Norwegian, Traditional Chinese, French, Finnish
HDCP version: 2.2
Packaging data
Package width: 824 mm
Package height: 554 mm
Package weight: 7.3 kg
Package depth: 119 mm
Packaging content
Cables included: AC, RS-232, HDMI
Batteries included: Yes
Remote control included: Yes
Display
Display resolution: 1920 x 1080 pixels
Response time: 8 ms
Display number of colours: 16.7 million colours
Native aspect ratio: 16:9
Display technology: LCD
Panel type: IPS
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Display diagonal: 80 cm (31.5")
Pixel pitch: 0.364 x 0.364 mm
Touchscreen: No
Maximum frame rate: 60 fps
Display diagonal (metric): 80 cm
Contrast ratio (typical): 1200:1
Viewing angle, horizontal: 178°
HD type: Full HD
Haze rate: 25%
Native refresh rate: 60 Hz
Display brightness: 500 cd/m²
RGB colour space: sRGB
Active display area (W x H): 698.4 x 392.85 mm
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 20 W
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB port: Yes
HDMI version: 2.0
DisplayPort version: 1.2
HDMI ports quantity: 2
USB version: 2.0
PC Audio in: Yes
USB ports quantity: 2
RS-232C: Yes
Audio Return Channel (ARC): Yes
Other features
Quick start guide: Yes
Power supply type: Internal
Housing material: Metal
Logistics data
Harmonized System (HS) code: 85285210
Computer system
Processor family: ARM Cortex
Operating system installed: Android 11
Processor cores: 4
On-board graphics card model: ARM Mali-G52
Built-in processor: Yes
Processor manufacturer: ARM
Internal memory: 4 GB
Processor architecture: ARM Cortex-A73
Internal storage capacity: 32 GB
