Technical details
Sustainability certificates: ErP
Audio in (mini jack): Yes
Compliance certificates: WEEE, RoHS, CE, REACH, TÜV mark, CB, EAC
Playback media: Y
Design
Orientation: Horizontal/Vertical
Bezel width (bottom): 1.4 cm
Bezel colour: Black
Bezel width (top): 1.4 cm
Bezel width (side): 1.35 cm
Panel mounting interface: 200 x 200
VESA mounting: Yes
Placement supported: Indoor
Power
Energy consumption (SDR) per 1000 hours: 107 kWh
Energy efficiency class (SDR): G
Energy efficiency class (HDR): Not available
Energy efficiency scale: A to G
Power consumption (standby): 0.4 W
AC input voltage: 100 - 240 V
Power consumption (typical): 107 W
AC input frequency: 50/60 Hz
Power consumption (off): 0.3 W
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Display depth: 54 mm
Display height: 557.5 mm
Display weight: 8.9 kg
Display width: 968 mm
Depth: 54 mm
Weight: 8.9 kg
Width: 968 mm
Height: 557.5 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Performance
Operating hours (hours/days): 24/7
HDCP version: 2.2
On Screen Display (OSD) languages: French, Russian, Japanese, Spanish, English, German, Italian, Dutch
On Screen Display (OSD): Yes
HDCP: Yes
Mean time between failures (MTBF): 50000 h
Purpose: Universal
Number of OSD languages: 11
Packaging data
Package width: 1075 mm
Package height: 683 mm
Package depth: 127 mm
Packaging content
Cables included: AC, HDMI, RS-232
Remote control included: Yes
Batteries included: Yes
Display
Active display area (W x H): 941.2 x 529.4 mm
Haze rate: 1%
Horizontal scan range: 30 - 80 kHz
Contrast ratio (typical): 1200:1
Touchscreen: No
Viewing angle, vertical: 178°
Viewing angle, horizontal: 178°
Response time: 8 ms
Panel type: IPS
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display diagonal (metric): 108 cm
Display brightness: 500 cd/m²
Native refresh rate: 60 Hz
Display number of colours: 1.07 billion colours
Display diagonal: 108 cm (42.5")
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Pixel pitch: 0.245 x 0.245 mm
Audio
Number of built-in speakers: 2
RMS rated power: 20 W
Built-in speaker(s): Yes
Ports & interfaces
Remote (IR) output: 1
Remote (IR) input: 1
RS-232C: Yes
HDMI ports quantity: 3
DVI port: Yes
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity: 1
PC Audio in: Yes
USB port: Yes
Ethernet LAN (RJ-45) ports: 1
Other features
Cable management: Yes
Power supply type: Internal
Quick start guide: Yes
Housing material: Metal
Logistics data
Harmonized System (HS) code: 85285210
Computer system
Computer system: Yes
Processor model: V810
Built-in processor: Yes
Operating system installed: Android 8.0
Internal memory: 2 GB
Internal storage capacity: 16 GB
