Technical details
Playback media: Y
Compliance certificates: UKCA, REACH, WEEE, TÜV mark, RoHS, CE, EAC
Sustainability certificates: ErP
Design
Product colour: Black
VESA mounting: Yes
Panel mounting interface: 400 x 400
Product design: Digital signage flat panel
Bezel colour: Black
Bezel width (bottom): 1.35 cm
Anti-glare screen: Yes
Orientation: Horizontal/Vertical
Bezel width (side): 1.32 cm
Placement supported: Indoor
Bezel width (top): 1.35 cm
Power
Power consumption (off): 0.3 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (typical): 112 W
Power consumption (standby): 0.4 W
Energy efficiency scale: A to G
Energy efficiency class (SDR): G
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 110 kWh
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 55 mm
Weight: 11.8 kg
Height: 643.6 mm
Width: 1122.7 mm
Display weight: 11.8 kg
Display height: 643.6 mm
Display depth: 55 mm
Display width: 1122.7 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Performance
HDCP: Yes
On Screen Display (OSD): Yes
Purpose: Universal
On Screen Display (OSD) languages: English, German, Traditional Chinese, Danish, Spanish, Japanese, Polish, Finnish, Italian, Dutch, Norwegian, Russian, Czech, Swedish, French
HDCP version: 2.2
Mean time between failures (MTBF): 44000 h
Operating hours (hours/days): 24/7
Number of OSD languages: 15
Packaging data
Package depth: 132 mm
Package weight: 16.2 kg
Package height: 761 mm
Package width: 1261 mm
Packaging content
Cables included: RS-232, AC, HDMI
Batteries included: Yes
Remote control included: Yes
Display
HD type: 4K Ultra HD
Touchscreen: No
Response time: 9.5 ms
Display diagonal: 125.7 cm (49.5")
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Pixel pitch: 0.285 x 0.285 mm
Display number of colours: 1.07 billion colours
Display resolution: 3840 x 2160 pixels
Viewing angle, horizontal: 178°
Native aspect ratio: 16:9
Panel type: VA
Maximum frame rate: 60 fps
Display technology: LCD
Display diagonal (metric): 125.7 cm
Native refresh rate: 60 Hz
Haze rate: 25%
Active display area (W x H): 1095.8 x 616.4 mm
Display brightness: 500 cd/m²
Contrast ratio (typical): 5000:1
RGB colour space: sRGB
Audio
Built-in speaker(s): Yes
Number of built-in speakers: 2
RMS rated power: 20 W
Ports & interfaces
HDMI version: 2.0
Card reader integrated: Yes
DisplayPort version: 1.2
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
Compatible memory cards: MicroSD (TransFlash)
HDMI ports quantity: 3
HDMI input ports quantity: 3
Audio Return Channel (ARC): Yes
Remote (IR) output: 1
USB port: Yes
RS-232C: Yes
DisplayPorts out: 1
USB version: 2.0
USB ports quantity: 2
Audio (L/R) out: 1
DisplayPorts in: 1
Remote (IR) input: 1
Other features
Quick start guide: Yes
Housing material: Metal
Power supply type: Internal
Logistics data
Harmonized System (HS) code: 85285210
Computer system
Internal memory: 4 GB
Built-in processor: Yes
Processor cores: 4
On-board graphics card model: ARM Mali-G52
Operating system installed: Android
Processor manufacturer: ARM
Processor family: ARM Cortex
Internal storage capacity: 32 GB
Operating system version: 11
Processor architecture: ARM Cortex-A73
