Technical details
Compliance certificates: TÜV mark, REACH, UKCA, RoHS, CE, EAC, WEEE
Sustainability certificates: ErP
Playback media: Y
Design
Product design: Digital signage flat panel
Product colour: Black
Panel mounting interface: 400 x 400
Placement supported: Indoor
VESA mounting: Yes
Bezel width (bottom): 1.28 cm
Bezel width (top): 1.28 cm
Orientation: Horizontal/Vertical
Anti-glare screen: Yes
Bezel colour: Black
Bezel width (side): 1.28 cm
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 135 W
Power consumption (off): 0.3 W
Power consumption (standby): 0.5 W
Energy efficiency class (SDR): G
Energy efficiency class (HDR): Not available
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 135 kWh
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Depth: 70 mm
Height: 709.2 mm
Width: 1238.4 mm
Weight: 13 kg
Display depth: 70 mm
Display weight: 13 kg
Display height: 709.2 mm
Display width: 1238.4 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Performance
Purpose: Universal
HDCP: Yes
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Japanese, Spanish, Polish, Russian, Czech, Danish, Swedish, German, Finnish, English, Norwegian, Traditional Chinese, French, Italian, Dutch
Number of OSD languages: 15
Operating hours (hours/days): 24/7
HDCP version: 1.4/2.0
Mean time between failures (MTBF): 50000 h
Packaging data
Package weight: 18.5 kg
Package height: 830 mm
Package depth: 144 mm
Package width: 1390 mm
Packaging content
Remote control included: Yes
Cables included: AC, RS-232, HDMI
Mounting kit: Yes
Batteries included: No
Display
Contrast ratio (typical): 5000:1
Display diagonal: 139.7 cm (55")
Display diagonal (metric): 138.7 cm
Display resolution: 3840 x 2160 pixels
Panel type: VA
Viewing angle, vertical: 178°
Viewing angle, horizontal: 178°
HD type: 4K Ultra HD
Pixel pitch: 0.315 x 0.315 mm
Display number of colours: 1.07 billion colours
Response time: 6.5 ms
Touchscreen: No
Horizontal scan range: 57 - 62 kHz
Native aspect ratio: 16:9
Display brightness: 500 cd/m²
Native refresh rate: 60 Hz
Haze rate: 25%
Number of displays: 1
Active display area (W x H): 1209.6 x 680.4 mm
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 20 W
Ports & interfaces
HDMI ports quantity: 2
HDMI version: 2.0
USB port: Yes
Ethernet LAN (RJ-45) ports: 1
USB version: 2.0
USB ports quantity: 2
USB Power Delivery (USB PD): Yes
RS-232C: Yes
USB Type-C DisplayPort Alternate Mode: Yes
USB Power Delivery up to: 15 W
Remote (IR) input: 1
Remote (IR) output: 1
Other features
Power supply type: Internal
Quick start guide: Yes
Computer system
Internal memory: 4 GB
On-board graphics card model: ARM Mali-G52
Built-in processor: Yes
Operating system installed: Android
Internal storage capacity: 32 GB
Processor architecture: ARM Cortex-A73
Operating system version: 14
