Technical details
Compliance certificates: RoHS, CE, REACH, UKCA, TÜV mark, WEEE
Playback media: Y
Sustainability certificates: ErP
Design
Panel mounting interface: 400 x 400 mm
VESA mounting: Yes
Product design: Kiosk design
Bezel colour: Black
Product colour: Black
Bezel width (bottom): 1.49 cm
Orientation: Horizontal/Vertical
Bezel width (side): 1.49 cm
Bezel width (top): 1.49 cm
Power
Power consumption (standby): 0.4 W
AC input voltage: 100 - 240 V
Power consumption (typical): 78 W
AC input frequency: 50/60 Hz
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 77.7 kWh
Energy efficiency class (SDR): E
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): -20 - 60%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Weight: 14.6 kg
Width: 1237.5 mm
Depth: 55 mm
Height: 710 mm
Display height: 710 mm
Display depth: 55 mm
Display weight: 14.6 kg
Display width: 1237.5 mm
Network
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Performance
Purpose: Commercial
On Screen Display (OSD) languages: Traditional Chinese, French, Finnish, Japanese, Russian, Czech, Spanish, English, Norwegian, German, Italian, Dutch, Swedish, Danish, Polish
On Screen Display (OSD): Yes
HDCP: Yes
Number of OSD languages: 8
Mean time between failures (MTBF): 50000 h
HDCP version: 2.2
Operating hours (hours/days): 24/7
Packaging data
Package width: 1386 mm
Package height: 845 mm
Package weight: 19.8 kg
Package depth: 130 mm
Packaging content
Remote control included: Yes
Cables included: RS-232, AC, HDMI
Display
Display technology: LED
Display resolution: 3840 x 2160 pixels
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Touchscreen: No
Display diagonal: 138.7 cm (54.6")
Native aspect ratio: 16:9
Pixel pitch: 0.315 x 0.315 mm
Display number of colours: 1.07 billion colours
Response time: 8 ms
HD type: 4K Ultra HD
Viewing angle, horizontal: 178°
Contrast ratio (typical): 1200:1
Display diagonal (metric): 139 cm
Panel type: IPS
Haze rate: 1%
Native refresh rate: 60 Hz
Display brightness: 800 cd/m²
Active display area (W x H): 1209.6 x 680.4 mm
RGB colour space: NTSC
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 20 W
Ports & interfaces
DisplayPort version: 1.2
USB port: Yes
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
HDMI ports quantity: 2
USB version: 2.0
HDMI version: 2.0
RS-232 interface: Yes
USB ports quantity: 2
RS-232C: Yes
Audio (L/R) in: 1
Remote (IR) input: 1
Other features
Power supply type: Internal
Quick start guide: Yes
Computer system
Processor manufacturer: ARM
Processor family: ARM Cortex
On-board graphics card model: ARM Mali-G52
Built-in processor: Yes
Processor cores: 8
Operating system installed: Android 11
Internal memory: 4 GB
Computer system: Yes
Processor architecture: ARM Cortex-A73
Internal storage capacity: 32 GB
