Technical details
Playback media: Y
Sustainability certificates: ErP
Compliance certificates: RoHS, CE, REACH, UKCA, WEEE, TÜV mark
Design
Product design: Kiosk design
Product colour: Black
VESA mounting: Yes
Panel mounting interface: 600 x 400 mm
Bezel width (bottom): 1.62 cm
Orientation: Horizontal/Vertical
Bezel colour: Black
Bezel width (side): 1.6 cm
Bezel width (top): 1.62 cm
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 159 W
Power consumption (off): 0.3 W
AC input frequency: 50/60 Hz
Power consumption (standby): 0.4 W
Energy efficiency class (HDR): Not available
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 159 kWh
Energy efficiency class (SDR): E
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): -20 - 60%
Weight & dimensions
Weight: 49 kg
Depth: 57 mm
Width: 1927 mm
Height: 1098.5 mm
Display weight: 49 kg
Display width: 1927 mm
Display height: 1098.5 mm
Display depth: 57 mm
Network
Wi-Fi: Yes
Ethernet LAN: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac)
Performance
HDCP: Yes
On Screen Display (OSD) languages: English, Japanese, Danish, Swedish, Finnish, Spanish, Polish, Russian, Czech, Traditional Chinese, French, Norwegian, German, Italian, Dutch
On Screen Display (OSD): Yes
Purpose: Commercial
Number of OSD languages: 8
Mean time between failures (MTBF): 50000 h
HDCP version: 2.2
Operating hours (hours/days): 24/7
Packaging data
Package width: 2123 mm
Package depth: 225 mm
Package height: 1247 mm
Package weight: 64 kg
Packaging content
Cables included: HDMI, RS-232, AC
Remote control included: Yes
Display
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Native aspect ratio: 16:9
Display number of colours: 1.07 billion colours
Viewing angle, horizontal: 178°
Response time: 8 ms
HD type: 4K Ultra HD
Pixel pitch: 0.315 x 0.315 mm
Display diagonal: 2.18 m (86")
Display resolution: 3840 x 2160 pixels
Display technology: LED
Panel type: IPS
Touchscreen: No
Display diagonal (metric): 217 cm
Contrast ratio (typical): 1200:1
Native refresh rate: 60 Hz
Display brightness: 800 cd/m²
Haze rate: 1%
RGB colour space: NTSC
Active display area (W x H): 1895 x 1066 mm
Audio
Number of built-in speakers: 2
Built-in speaker(s): Yes
RMS rated power: 20 W
Ports & interfaces
DisplayPorts quantity: 1
DisplayPort version: 1.2
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.0
USB version: 2.0
RS-232 interface: Yes
USB port: Yes
HDMI ports quantity: 2
USB ports quantity: 2
RS-232C: Yes
Audio (L/R) in: 1
Other features
Quick start guide: Yes
Power supply type: Internal
Computer system
On-board graphics card model: ARM Mali-G52
Processor cores: 8
Internal memory: 4 GB
Processor family: ARM Cortex
Processor manufacturer: ARM
Built-in processor: Yes
Operating system installed: Android 11
Processor architecture: ARM Cortex-A73
Computer system: Yes
Internal storage capacity: 32 GB
