Processor
Performance cores: 4
Efficient-core Max Turbo Frequency: 3.3 GHz
Performance-core Max Turbo Frequency: 4.4 GHz
Maximum turbo power: 95 W
Processor cores: 8
Processor generation: 12th gen Intel® Core™ i5
Processor manufacturer: Intel
Efficient cores: 4
Processor cache type: Smart Cache
Processor base power: 45 W
Processor family: Intel® Core™ i5
Processor cache: 12 MB
Processor model: i5-12450H
Graphics
On-board GPU manufacturer: Intel
Discrete graphics card: No
On-board graphics card: Yes
Discrete graphics card model: Not available
On-board graphics card model: Intel® UHD Graphics
On-board graphics card family: Intel® UHD Graphics
Memory
Memory clock speed: 3200 MHz
Internal memory: 8 GB
Maximum internal memory: 32 GB, 32 MB
Internal memory type: DDR4-SDRAM
Design
Chassis type: Mini PC
Product colour: Black
Power
Power consumption (standby): 2.9 W
Power consumption (typical): 80.7 W
Operational conditions
Storage relative humidity (H-H): 10 - 95%
Operating relative humidity (H-H): 10 - 95%
Storage temperature (T-T): -10 - 50 °C
Operating temperature (T-T): 0 - 45 °C
Weight & dimensions
Weight: 600 g
Depth: 180 mm
Width: 119 mm
Height: 30 mm
Network
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Bluetooth: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Bluetooth version: 5.2
Performance
Product type: Mini PC
Trusted Platform Module (TPM): Yes
Trusted Platform Module (TPM) version: 2.0
Packaging data
Package width: 260 mm
Package height: 192 mm
Package depth: 72 mm
Package weight: 957 g
Display
Display included: No
Compatible operating systems: Windows 11 IoT Enterprise
Software
Operating system installed: Windows 11 IoT Enterprise
Operating system architecture: 64-bit
Audio
Audio system: High Definition Audio
Storage
SSD interface: PCI Express
Number of SSDs installed: 1
Total storage capacity: 256 GB
SSD form factor: M.2
Total SSDs capacity: 256 GB
Optical drive type: No
SSD capacity: 256 GB
Storage media: SSD
Ports & interfaces
DisplayPorts quantity: 1
HDMI version: 2.0
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
HDMI ports quantity: 1
DisplayPort version: 1.4
