Design
Market positioning: Graphics design
Product colour: Black
Power
Input current: 2.3 A
AC input voltage: 100 - 240 V
Power consumption (typical): 27 W
Power supply type: Internal
Power consumption (standby): 0.5 W
AC input frequency: 50/60 Hz
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
Energy efficiency class (HDR): G
Energy consumption (HDR) per 1000 hours: 37 kWh
Energy consumption (SDR) per 1000 hours: 27 kWh
Energy efficiency class (SDR): G
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 80%
Weight & dimensions
Width (with stand): 614 mm
Height (with stand): 544 mm
Depth (with stand): 224.5 mm
Weight (with stand): 6.7 kg
Height (without stand): 404 mm
Network
Ethernet LAN: Yes
Performance
Flicker-free technology: Yes
Low Blue Light technology: Yes
Packaging data
Package width: 688 mm
Package type: Box
Package weight: 9.7 kg
Package height: 463 mm
Package depth: 138 mm
USB cable length: 1.8 m
Packaging content
Cables included: AC, DisplayPort, USB, HDMI, USB Type-C
HDMI cable length: 1.8 m
DisplayPort cable length: 1.8 m
Power cable length: 1.8 m
Display
Vertical scan range: 40 - 60 Hz
Display surface: Matt
Pixel pitch: 0.155 x 0.155 mm
Native aspect ratio: 16:9
Display technology: LCD
Contrast ratio (typical): 3000:1
Horizontal scan range: 30 - 140 kHz
Display number of colours: 1.07 billion colours
Viewing angle, vertical: 178°
Display brightness (typical): 450 cd/m²
Display diagonal (metric): 68.5 cm
Panel type: IPS Black
Touchscreen: No
Screen shape: Flat
Display resolution: 3840 x 2160 pixels
Viewable size, horizontal: 59.7 cm
Viewing angle, horizontal: 178°
Display diagonal: 68.6 cm (27")
HD type: 4K Ultra HD
Response time: 4 ms
Response time measurement type: GTG (Gray to Gray)
Viewable size, vertical: 33.6 cm
DCI-P3 coverage: 99%
High Dynamic Range (HDR) technology: High Dynamic Range (HDR) 400
sRGB coverage (typical): 100%
High Dynamic Range (HDR) supported: Yes
NTSC coverage (typical): 72%
Maximum refresh rate: 60 Hz
Colour gamut standard: sRGB, NTSC, DCI-P3
Colour depth: 8 bit
DDC/CI: Yes
Multimedia
Built-in speaker(s): Yes
Number of speakers: 2
RMS rated power: 4 W
Ergonomics
Panel mounting interface: 100 x 100 mm
Cable lock slot: Yes
Pivot: Yes
Cable lock slot type: Kensington
Swivelling: Yes
Tilt adjustment: Yes
Tilt angle range: -5 - 23°
VESA mounting: Yes
Height adjustment: Yes
Swivel angle range: 0 - 360°
Adjustable height (max): 15 cm
Cable management: Yes
On Screen Display (OSD) languages: Japanese, German, Italian, Dutch, Spanish, French, English, Polish, Ukrainian, Russian, Czech
Ports & interfaces
Headphone outputs: 1
Built-in USB hub: Yes
HDCP: Yes
HDMI ports quantity: 1
DisplayPort out quantity: 1
DisplayPorts quantity: 1
Number of downstream ports: 4
Headphone out: Yes
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
USB Type-C downstream ports quantity: 1
USB Type-C DisplayPort Alternate Mode: Yes
Number of USB Type-C upstream ports quantity: 1
USB Power Delivery (USB PD): Yes
USB upstream port type: USB Type-C, USB Type-B
Number of upstream ports: 2
HDMI: Yes
Headphone connectivity: 3.5 mm
Number of USB Type-B upstream ports quantity: 1
USB Power Delivery up to: 96 W
Built-in KVM switch: Yes
USB Type-A downstream ports quantity: 3
Packaging content: quick start guide, safety guide
Other features
Ethernet LAN (RJ-45) ports: 1
Depth: 224.5 mm
Width: 614 mm
Weight: 6.7 kg
Compliance certificates: VCCI, PSE, TÜV mark, REACH, UKCA, RoHS, CE, WEEE, EAC
Control panel: Joystick/Power: Up/Input Select, Down/Shortcut, Right/Shortcut, Left/Shortcut
Sustainability
Sustainability certificates: TCO, ErP
