Design
Market positioning: Business
Product colour: Black
Front bezel colour: Black
Power
Power consumption (off): 0.3 W
AC input voltage: 100 - 240 V
Power consumption (standby): 0.6 W
AC input frequency: 50/60 Hz
Power supply type: Internal
Power consumption (typical): 20 W
European Product Registry for Energy Labelling (EPREL) code: 1518676
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 0 kWh
Energy consumption (HDR) per 1000 hours: 0 kWh
Energy efficiency class (SDR): E
Weight & dimensions
Height (with stand): 378 mm
Depth (with stand): 240 mm
Width (with stand): 387 mm
Weight (with stand): 4.9 kg
Network
Ethernet LAN: No
Wi-Fi: No
Performance
NVIDIA G-SYNC: No
AMD FreeSync: No
Packaging content
Quick start guide: Yes
Cables included: HDMI, Audio, AC, DisplayPort, USB
Display
Response time: 5 ms
Viewing angle, vertical: 160°
Viewing angle, horizontal: 170°
Native aspect ratio: 5:4
Display technology: LED
Panel type: TN
Display brightness (typical): 250 cd/m²
Display diagonal (metric): 43 cm
Horizontal scan range: 31 - 80 kHz
Touchscreen: Yes
Screen shape: Flat
Aspect ratio: 5:4
Viewable size, horizontal: 33.8 cm
Display resolution: 1280 x 1024 pixels
Contrast ratio (typical): 1000:1
Display diagonal: 43.2 cm (17")
Pixel pitch: 0.264 x 0.264 mm
Display number of colours: 16.7 million colours
Display brightness: 225 cd/m²
Viewable size, vertical: 27.1 cm
Touchscreen type: Table
Touchscreen technology: Projected capacitive system
Number of simultaneous touchpoints: 10
Multimedia
Built-in speaker(s): Yes
Built-in camera: No
Number of speakers: 2
RMS rated power: 2 W
Ergonomics
Tilt adjustment: Yes
Cable lock slot type: Kensington
VESA mounting: Yes
Panel mounting interface: 100 x 100 mm
Cable lock slot: Yes
On Screen Display (OSD): Yes
Height adjustment: No
Cable management: Yes
On Screen Display (OSD) languages: Japanese, English, Spanish, German, Italian, Traditional Chinese, French
Ports & interfaces
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 1
HDCP: Yes
HDMI ports quantity: 1
Built-in USB hub: No
DVI port: No
Headphone out: No
HDMI: Yes
Audio input: Yes
USB Touch port: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CE, EAC, RoHS support, ErP, WEEE, cULus, VCCI, REACH, UKCA
Other features
Weight: 4.9 kg
Depth: 240 mm
Width: 387 mm
Built-in processor: No
International Protection (IP) code: IP54
Height: 378 mm
Placement supported: Indoor
Compliance certificates: VCCI, REACH, UKCA, RoHS, CE, EAC, cULus, WEEE
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power
Multi-touch: Yes
Touch method: stylus, finger, glove (latex)
Active display area (W x H): 338 x 270.5 mm
Brightness: 225 cd/m²
Sustainability
Sustainability certificates: ErP
