Design
Product colour: Black
Front bezel colour: Black
Glass thickness: 2.4 mm
Market positioning: Office
Power
Power consumption (typical): 18 W
AC adapter output voltage: 12 V
Power consumption (off): 0.3 W
Power supply type: External
Power consumption (standby): 0.7 W
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 10.1 kWh
Energy efficiency class (SDR): E
Energy efficiency class (HDR): Not available
Weight & dimensions
Depth (with stand): 200 mm
Width (with stand): 381 mm
Height (with stand): 285.5 mm
Weight (with stand): 3.4 kg
Performance
Palm rejection: Yes
Packaging data
Package depth: 150 mm
Package height: 355 mm
Package weight: 5.18 kg
Package width: 445 mm
Packaging content
Cables included: DisplayPort, HDMI, AC, USB
Quick start guide: Yes
Display
Pixel pitch: 0.179 x 0.179 mm
Display diagonal: 39.6 cm (15.6")
Display resolution: 1920 x 1080 pixels
Digital horizontal frequency: 30 - 84 kHz
Display surface: Matt
Response time: 25 ms
Display number of colours: 16.2 million colours
Viewing angle, horizontal: 178°
HD type: Full HD
Viewing angle, vertical: 178°
Horizontal scan range: 30 - 84 kHz
Screen shape: Flat
Native aspect ratio: 16:9
Display brightness (typical): 450 cd/m²
Surface hardness: 7H
Display brightness: 405 cd/m²
Viewable size, vertical: 19.4 cm
Number of simultaneous touchpoints: 10
Display diagonal (metric): 39.5 cm
Panel type: IPS
Display brightness (peak): 450 cd/m²
Contrast ratio (typical): 700:1
Touchscreen: Yes
Colour depth: 6 bit
Maximum refresh rate: 60 Hz
Viewable size, horizontal: 34.4 cm
Response time measurement type: GTG (Gray to Gray)
Colour gamut: 90%
Touchscreen technology: Projected capacitive system
Display technology: LED
Response time (fast): 25 ms
Ergonomics
Panel mounting interface: 100 x 100 mm
Tilt angle range: 90 - 5°
On Screen Display (OSD) languages: Japanese, Spanish, German, Italian, English, Traditional Chinese, French
VESA mounting: Yes
Tilt adjustment: Yes
On Screen Display (OSD): Yes
Ports & interfaces
DisplayPorts quantity: 1
HDCP: Yes
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
HDMI: Yes
USB Touch port: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Packaging content: AC adapter
Other features
Weight: 3.4 kg
AC adapter included: Yes
Width: 381 mm
International Protection (IP) code: IP65
Depth: 200 mm
Height: 285.5 mm
Touch method: stylus, finger, glove (latex)
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Second display effective viewing area: 344.2 x 193.6 mm
Compliance certificates: EAC, cULus, RoHS, CE, REACH, WEEE, UKCA
Active display area (W x H): 344.2 x 193.6 mm
Brightness: 405 cd/m²
Sustainability
Sustainability certificates: ErP
