Design
Product colour: Black
Market positioning: Business
Front bezel colour: Black
Feet colour: Black
Glass thickness: 1.5 mm
Power
Power consumption (standby): 1.5 W
Power consumption (off): 0.3 W
AC adapter output voltage: 12 V
Power consumption (typical): 20 W
Energy efficiency class (SDR): E
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 13 kWh
European Product Registry for Energy Labelling (EPREL) code: 1385536
Power supply type: External
Energy efficiency scale: A to G
Weight & dimensions
Height (with stand): 364 mm
Width (with stand): 392.5 mm
Depth (with stand): 198 mm
Weight (with stand): 4.4 kg
Performance
NVIDIA G-SYNC: No
Low Blue Light technology: Yes
AMD FreeSync: No
Packaging data
Package weight: 5.8 kg
Package width: 537 mm
Package height: 500 mm
Package depth: 172 mm
Packaging content
Cables included: HDMI, AC, USB
Quick start guide: Yes
Manual: Yes
Stand included: Yes
Power adapter included: Yes
Display
Horizontal scan range: 31.4 - 80 kHz
Viewing angle, vertical: 160°
Display number of colours: 16.7 million colours
HD type: SXGA
Touchscreen: Yes
Viewing angle, horizontal: 170°
Response time: 5 ms
Display brightness (typical): 250 cd/m²
Display resolution: 1280 x 1024 pixels
Pixel pitch: 0.264 x 0.264 mm
Display surface: Matt
Display diagonal: 43.2 cm (17")
Screen shape: Flat
Native aspect ratio: 5:4
Viewable size, vertical: 27.1 cm
Display brightness: 230 cd/m²
Touch technology: Multi-touch
Surface hardness: 7H
Touchscreen technology: Projected capacitive system
Display technology: LED
Display brightness (peak): 230 cd/m²
DDC/CI: Yes
Display diagonal (metric): 43 cm
Panel type: TN
Touchscreen type: Tabletop
Viewable size, horizontal: 33.8 cm
Contrast ratio (typical): 1000:1
Backlight type: LED
Number of simultaneous touchpoints: 10
Multimedia
RMS rated power: 4 W
Number of speakers: 2
Built-in camera: No
Built-in speaker(s): Yes
Ergonomics
VESA mounting: Yes
On Screen Display (OSD): Yes
Tilt adjustment: Yes
Tilt angle range: 10 - 70°
Panel mounting interface: 100 x 100 mm
On Screen Display (OSD) languages: Japanese, Spanish, English, German, Italian, Traditional Chinese, French
Cable management: Yes
Number of OSD languages: 8
Ports & interfaces
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
HDCP: Yes
Built-in USB hub: Yes
USB Touch port: Yes
Headphone out: Yes
HDMI: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CE, RoHS support, ErP, WEEE, cULus, REACH, UKCA
Packaging content: AC adapter, mylar sheet (for VESA mount)
Other features
Height: 364 mm
International Protection (IP) code: IPX3
Width: 392.5 mm
Depth: 198 mm
AC adapter included: Yes
Weight: 4.4 kg
Touch method: stylus, finger, glove (latex)
Compliance certificates: cULus, REACH, WEEE, UKCA, RoHS, CE
Control panel: Menu, Up/Left/ Auto adjustment button, Down/Right button, Return/Exit button, Power
Active display area (W x H): 338 x 270.5 mm
Mean time between failures (MTBF): 50000 h
Brightness: 230 cd/m²
USB ports quantity: 1
Sustainability
Sustainability compliance: Yes
Sustainability certificates: ErP
