Design
Front bezel colour: Black
Power
Power consumption (off): 0.3 W
Energy efficiency class (SDR): E
Power consumption (typical): 20 W
AC input voltage: 100 - 240 V
Power supply type: Internal
Power consumption (standby): 1.5 W
Weight & dimensions
Width (with stand): 387 mm
Height (with stand): 378 mm
Depth (with stand): 239.5 mm
Weight (with stand): 5.4 kg
Packaging data
Package height: 445 mm
Package width: 470 mm
Package depth: 180 mm
Package weight: 7.3 kg
USB cable length: 1.8 m
Packaging content
Quick start guide: Yes
Cables included: DisplayPort, USB, HDMI, Audio, AC
DisplayPort cable length: 1.8 m
Audio cable length: 1.8 m
HDMI cable length: 1.8 m
Power cable length: 1.8 m
Display
Display diagonal: 43.2 cm (17")
Display brightness (typical): 250 cd/m²
Pixel pitch: 0.264 x 0.264 mm
Touchscreen: Yes
Horizontal scan range: 31 - 80 kHz
Response time: 5 ms
Native aspect ratio: 5:4
Display number of colours: 16.7 million colours
Display resolution: 1280 x 1024 pixels
Display diagonal (metric): 43 cm
Display brightness: 195 cd/m²
Viewable size, horizontal: 33.8 cm
Contrast ratio (typical): 1000:1
Viewable size, vertical: 27 cm
Touchscreen technology: Resistive
Maximum refresh rate: 75 Hz
Panel type: TN
Number of simultaneous touchpoints: 1
Multimedia
Built-in speaker(s): Yes
RMS rated power: 2 W
Number of speakers: 2
Ergonomics
Tilt adjustment: Yes
VESA mounting: Yes
Panel mounting interface: 100 x 100 mm
Cable lock slot: Yes
Cable lock slot type: Kensington
Cable management: Yes
On Screen Display (OSD) languages: Japanese, Polish, Russian, French, English, Spanish, Portuguese, German, Italian, Dutch
On Screen Display (OSD): Yes
Ports & interfaces
VGA (D-Sub) ports quantity: 1
HDCP: Yes
DisplayPorts quantity: 1
Audio input: Yes
USB Touch port: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Packaging content: Screwdriver
Other features
Height: 378 mm
Depth: 239.5 mm
Width: 387 mm
Touch method: stylus, finger, glove, glove (latex)
International Protection (IP) code: IP54
Weight: 5.4 kg
Active display area (W x H): 338 x 270 mm
Brightness: 195 cd/m²
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power
Mean time between failures (MTBF): 50000 h
Compliance certificates: REACH, RoHS, CE, EAC, cULus, VCCI, WEEE, UKCA
Sustainability
Sustainability certificates: ErP
