Design
Product colour: Black
Front bezel colour: Black
Market positioning: Business
Power
AC input voltage: 100 - 240 V
Power consumption (off): 0.3 W
AC input frequency: 50/60 Hz
Energy efficiency scale: A to G
Power supply type: Internal
Power consumption (standby): 0.5 W
Power consumption (typical): 17 W
Energy consumption (SDR) per 1000 hours: 17 kWh
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): E
Operational conditions
Storage relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 5 - 35 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Width (with stand): 540 mm
Depth (with stand): 241 mm
Height (with stand): 373 mm
Weight (with stand): 5.4 kg
Performance
Windows operating systems supported: Yes
NVIDIA G-SYNC: No
AMD FreeSync: No
OmniTapps Multitouch compatibility: Yes
Flicker-free technology: Yes
Linux operating systems supported: Yes
Low Blue Light technology: Yes
Packaging data
Package weight: 7.1 kg
Package width: 615 mm
Package depth: 148 mm
Package height: 420 mm
Packaging content
Quick start guide: Yes
Cables included: USB, HDMI, AC
Display
Display diagonal: 60.5 cm (23.8")
Display brightness (typical): 300 cd/m²
Screen shape: Flat
Contrast ratio (dynamic): 5000000:1
Viewing angle, horizontal: 178°
HD type: Full HD
Native aspect ratio: 16:9
Horizontal scan range: 30 - 83 kHz
LED backlight: Yes
Response time: 4 ms
Supported graphics resolutions: 1280 x 1024 (SXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 800 x 600 (SVGA), 1024 x 768 (XGA), 1440 x 900 (WXGA+), 640 x 480 (VGA)
Viewing angle, vertical: 178°
Display resolution: 1920 x 1080 pixels
Pixel pitch: 0.2745 x 0.2745 mm
Display number of colours: 16.7 million colours
Response time measurement type: GTG (Gray to Gray)
Maximum refresh rate: 83 Hz
Touchscreen type: Multi-user
Display brightness: 300 cd/m²
Viewable size, vertical: 29.6 cm
Touch technology: Multi-touch
Surface hardness: 3H
Display diagonal (metric): 60.5 cm
Contrast ratio (typical): 1000:1
Touchscreen technology: Projected capacitive system
Display technology: LED
Anti-glare screen: Yes
Viewable size, horizontal: 52.7 cm
Touchscreen: Yes
Panel type: IPS
Colour depth: 8 bit
Number of simultaneous touchpoints: 10
Multimedia
Megapixel (approx.): 2.1 MP
Number of speakers: 2
Built-in camera: No
Built-in speaker(s): Yes
RMS rated power: 4 W
Ergonomics
Cable lock slot type: Kensington
Tilt angle range: -5 - 90°
Cable lock slot: Yes
Adjustable height (max): 11.1 cm
Height adjustment: Yes
On Screen Display (OSD): Yes
Number of OSD languages: 10
Wall mountable: Yes
On Screen Display (OSD) languages: Polish, Japanese, English, Russian, German, Italian, Dutch, Spanish, French, Portuguese
Plug and Play: Yes
Cable management: Yes
VESA mounting: Yes
Panel mounting interface: 100 x 100 mm
Tilt adjustment: Yes
Ports & interfaces
HDCP: Yes
DisplayPorts quantity: 1
Number of downstream ports: 2
HDMI ports quantity: 1
Number of upstream ports: 1
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
Headphone out: Yes
HDMI: Yes
USB Type-A downstream ports quantity: 2
USB Touch port: Yes
Built-in USB hub: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CE, TÜV-Bauart, VCCI-B, EAC, ErP, WEEE, REACH, CB
Packaging content: Screwdriver
Other features
Full HD: Yes
Weight: 5.4 kg
Positional accuracy: 2 mm
Compliance certificates: UKCA, REACH, EAC, RoHS, CE, WEEE
Width: 540 mm
Control panel: Power, menu, +, -, Exit
Height: 373 mm
USB ports quantity: 2
Depth: 241 mm
Active display area (W x H): 527.04 x 296.46 mm
Placement supported: Horizontal/Vertical
Mean time between failures (MTBF): 50000 h
Touch method: finger, glove (latex), capacitive stylus
Logistics data
Harmonized System (HS) code: 85285210
Sustainability
Sustainability certificates: ErP, EPEAT
