Design
Front bezel colour: Black
Market positioning: Business
Glass thickness: 3.3 mm
Product colour: Black
Power
Power consumption (standby): 1.5 W
Power consumption (typical): 18 W
Energy efficiency class (SDR): E
Energy efficiency class (HDR): Not available
Power supply type: External
AC adapter output voltage: 12 V
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 11 kWh
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Height (with stand): 246 mm
Depth (without stand): 42 mm
Width (with stand): 398.5 mm
Weight (with stand): 2.5 kg
Width (without stand): 398.5 mm
Weight (without stand): 2.5 kg
Depth (with stand): 42 mm
Height (without stand): 246 mm
Packaging data
Package height: 145 mm
Package width: 470 mm
Package weight: 4.3 kg
Package type: Box
Package depth: 343 mm
Packaging content
Quick start guide: Yes
Power adapter included: Yes
Cables included: HDMI, USB, AC, DisplayPort
Display
Viewing angle, vertical: 178°
Display resolution: 1920 x 1080 pixels
Horizontal scan range: 31.5 - 67.5 kHz
Aspect ratio: 16:9
Contrast ratio (typical): 1000:1
Screen shape: Flat
Native aspect ratio: 16:9
Response time: 25 ms
Viewable size, horizontal: 34.5 cm
Pixel pitch: 0.17925 x 0.17925 mm
Number of simultaneous touchpoints: 10
Touchscreen: Yes
Viewable size, vertical: 19.5 cm
Display brightness (peak): 450 cd/m²
Display brightness (typical): 450 cd/m²
Touchscreen technology: Projected capacitive system
Panel type: IPS
Display brightness: 405 cd/m²
Surface hardness: 7H
Display diagonal: 39.6 cm (15.6")
HD type: Full HD
Viewing angle, horizontal: 178°
Display diagonal (metric): 39.5 cm
Ergonomics
On Screen Display (OSD) languages: English, Japanese, German, Italian, Spanish, Traditional Chinese, French
Panel mounting interface: 100 x 100 mm
VESA mounting: Yes
On Screen Display (OSD): Yes
Ports & interfaces
VGA (D-Sub) ports quantity: 1
Headphone out: Yes
USB Touch port: Yes
Built-in USB hub: Yes
DisplayPorts quantity: 1
HDMI: Yes
HDCP: Yes
Certification: CE, EAC, RoHS support, ErP, WEEE, cULus, REACH, UKCA
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Packaging content: AC adapter, external control pad
Other features
Mean time between failures (MTBF): 50000 h
Width: 398.5 mm
Control panel: menu,scroll up/ brightness, scroll down/ contrast, select, power
Weight: 2.5 kg
Active display area (W x H): 345.2 x 194.6 mm
Brightness: 405 cd/m²
Height: 246 mm
Touch method: stylus, finger, glove (latex)
Depth: 42 mm
International Protection (IP) code: IP65
AC adapter included: Yes
Compliance certificates: RoHS, CE, WEEE, REACH, UKCA, EAC, cULus
Sustainability
Sustainability certificates: ErP
