Design
Front bezel colour: Black
Glass thickness: 3 mm
Power
Power consumption (off): 0.3 W
AC adapter output voltage: 12 V
Power consumption (standby): 1.5 W
Power supply type: External
Power consumption (typical): 13 W
Energy efficiency class (SDR): E
Weight & dimensions
Depth (with stand): 47.5 mm
Width (with stand): 369 mm
Height (with stand): 307 mm
Weight (with stand): 3.6 kg
Performance
Palm rejection: Yes
Packaging data
Package weight: 5.2 kg
Package width: 387 mm
Package height: 145 mm
Package depth: 455 mm
USB cable length: 1.8 m
Packaging content
Quick start guide: Yes
Cables included: DisplayPort, AC, HDMI, USB
Power cable length: 1.8 m
DisplayPort cable length: 1.8 m
HDMI cable length: 1.8 m
Display
Display resolution: 1280 x 1024 pixels
Display brightness (typical): 350 cd/m²
Viewing angle, vertical: 160°
Response time: 5 ms
Native aspect ratio: 5:4
Display diagonal: 43.2 cm (17")
Viewing angle, horizontal: 170°
Pixel pitch: 0.264 x 0.264 mm
Display number of colours: 16.7 million colours
Contrast ratio (typical): 1000:1
Display diagonal (metric): 43 cm
Horizontal scan range: 31 - 80 kHz
Viewable size, vertical: 27 cm
Display brightness: 300 cd/m²
Maximum refresh rate: 75 Hz
Viewable size, horizontal: 33.8 cm
Touchscreen technology: Projected capacitive system
Panel type: TN
Touchscreen: Yes
Number of simultaneous touchpoints: 10
Ergonomics
Panel mounting interface: 100 x 100 mm
VESA mounting: Yes
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: German, Italian, Dutch, Spanish, Russian, Japanese, Portuguese, English, French, Polish
Ports & interfaces
HDCP: Yes
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 1
USB Touch port: Yes
Packaging content: AC adapter
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Weight: 3.6 kg
AC adapter included: Yes
Positional accuracy: 2 mm
Width: 369 mm
International Protection (IP) code: IP65
Depth: 47.5 mm
Height: 307 mm
Touch method: stylus, finger, glove (latex)
Active display area (W x H): 338 x 270 mm
Brightness: 300 cd/m²
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Compliance certificates: UKCA, RoHS, CE, EAC, cULus, WEEE, REACH
Sustainability
Sustainability certificates: ErP
