Design
Front bezel colour: Black
Glass thickness: 6 mm
Product colour: Black
Power
Energy efficiency class (SDR): F
Energy consumption (SDR) per 1000 hours: 18 kWh
Energy efficiency scale: A to G
Power consumption (standby): 1.5 W
Power consumption (off): 1.5 W
AC adapter output voltage: 12 V
Power supply type: External
Power consumption (typical): 21 W
Weight & dimensions
Depth (without stand): 46.5 mm
Height (without stand): 344 mm
Weight (with stand): 4.4 kg
Width (without stand): 416 mm
Weight (without stand): 4.4 kg
Width (with stand): 416 mm
Height (with stand): 344 mm
Depth (with stand): 46.5 mm
Performance
Palm rejection: Yes
AMD FreeSync: No
NVIDIA G-SYNC: No
Packaging data
Package width: 16.4 mm
Package depth: 1.8 mm
Package height: 13.5 mm
Packaging content
Cables included: HDMI, USB, AC, DisplayPort
Quick start guide: Yes
Display
Display brightness: 315 cd/m²
Touchscreen technology: Projected capacitive system
Touch technology: Multi-touch
Number of simultaneous touchpoints: 10
Viewable size diagonal: 48 cm
Aspect ratio: 5:4
Viewable size, horizontal: 37.6 cm
Display diagonal: 48.3 cm (19")
HD type: SXGA
Viewing angle, horizontal: 178°
Display resolution: 1280 x 1024 pixels
Display number of colours: 16.7 million colours
Pixel pitch: 0.294 x 0.294 mm
Viewable size, vertical: 30.1 cm
Screen shape: Flat
Display brightness (typical): 350 cd/m²
Contrast ratio (dynamic): 1000:1
Display technology: LED
Panel type: IPS
Touchscreen: Yes
LED backlight: Yes
Native aspect ratio: 5:4
Response time measurement type: GTG (Gray to Gray)
Viewing angle, vertical: 178°
Response time: 14 ms
Contrast ratio (typical): 1000:1
Backlight type: LED
Supported graphics resolutions: 1280 x 1024 (SXGA)
Display diagonal (metric): 48 cm
Horizontal scan range: 31.4 - 80 kHz
Multimedia
Built-in camera: No
Built-in microphone: No
Ergonomics
Wall mountable: Yes
Number of OSD languages: 7
VESA mounting: Yes
On Screen Display (OSD) languages: Japanese, German, Italian, Spanish, Traditional Chinese, French, English
On Screen Display (OSD): Yes
Panel mounting interface: 100 x 100 mm
Ports & interfaces
USB Touch port: Yes
HDMI: Yes
HDCP: Yes
HDMI ports quantity: 1
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 1
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CE, EAC, RoHS support, ErP, WEEE, cULus, REACH, REACH SVHC above 0.1%: Lead
Packaging content: AC adapter, Touch Panel Driver Disk (CD-ROM)
Other features
Display viewable area (HxV): 376.5 x 301.1 mm
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Active display area (W x H): 376.5 x 301.1 mm
Brightness: 315 cd/m²
Touch method: stylus, finger, glove (latex)
Height: 344 mm
AC adapter included: Yes
Depth: 46.5 mm
Compliance certificates: RoHS, CE, REACH, EAC, cULus, WEEE
Supplied AC adapter type: Yes
Weight: 4.4 kg
International Protection (IP) code: IP65
Width: 416 mm
Logistics data
Harmonized System (HS) code: 85285210
Sustainability
Sustainability certificates: ErP
