Design
Product colour: Black
Front bezel colour: Black
Power
European Product Registry for Energy Labelling (EPREL) code: 378611
Power consumption (typical): 20.8 W
Power consumption (standby): 1.05 W
Power supply type: External
AC adapter output voltage: 12 V
Power consumption (off): 0.32 W
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 19 kWh
Energy efficiency class (SDR): F
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Width (with stand): 520 mm
Depth (with stand): 42.5 mm
Height (with stand): 315 mm
Width (without stand): 520 mm
Height (without stand): 315 mm
Depth (without stand): 42.5 mm
Weight (without stand): 4.4 kg
Weight (with stand): 4.4 kg
Performance
NVIDIA G-SYNC: No
AMD FreeSync: No
OmniTapps Multitouch compatibility: No
Packaging content
Cables included: HDMI, DisplayPort, USB, AC
Quick start guide: Yes
Display
Display resolution: 1920 x 1080 pixels
Screen shape: Flat
Aspect ratio: 16:9
HD type: Full HD
Touchscreen: Yes
Viewing angle, horizontal: 178°
Display technology: LED
Native aspect ratio: 16:9
Response time: 14 ms
Panel type: IPS
Horizontal scan range: 31.4 - 82 kHz
Display diagonal: 54.6 cm (21.5")
Separate H/V sync: Yes
Vertical scan range: 56 - 75 Hz
Display brightness (typical): 350 cd/m²
Display diagonal (metric): 54.6 cm
Viewing angle, vertical: 178°
Display number of colours: 16.78 million colours
Viewable size, horizontal: 47.6 cm
Viewable size, vertical: 26.8 cm
Contrast ratio (typical): 1000:1
Pixel pitch: 0.24795 x 0.24795 mm
Touch technology: Multi-touch
Display brightness: 315 cd/m²
Touchscreen technology: Projected capacitive system
Touchscreen type: Multi-user
Surface hardness: 7H
Number of simultaneous touchpoints: 10
Multimedia
Built-in microphone: No
Built-in camera: No
Ergonomics
VESA mounting: Yes
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: German, Italian, Japanese, English, Spanish, Traditional Chinese, French
Panel mounting interface: 100 x 100 mm
Plug and Play: Yes
Wall mountable: Yes
Number of OSD languages: 6
Ports & interfaces
DisplayPorts quantity: 1
Headphone outputs: 1
VGA (D-Sub) ports quantity: 1
HDCP: Yes
HDMI ports quantity: 1
HDMI: Yes
USB Touch port: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: CB, CE, TÜV-Bauart, CU, cULus, REACH
Packaging content: AC adapter, Touch Panel Driver Disk (CD-ROM), external control pad
Other features
Compliance certificates: RoHS, CE, CB, cULus, REACH, WEEE
Height: 315 mm
Depth: 42.5 mm
AC adapter included: Yes
Full HD: Yes
International Protection (IP) code: IP65
Placement supported: Horizontal/Vertical
Weight: 4.4 kg
Width: 520 mm
Active display area (W x H): 476.064 x 267.786 mm
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Display viewable area (HxV): 476.064 x 267.786 mm
Brightness: 315 cd/m²
Touch method: stylus, finger, glove (latex)
Logistics data
Harmonized System (HS) code: 85285210
Sustainability
Sustainability certificates: ErP
