Design
Housing material: Metal
Front bezel colour: Black
Product colour: Black
Market positioning: Office
Glass thickness: 3 mm
Power
Energy consumption (SDR) per 1000 hours: 27.5 kWh
AC input frequency: 50/60 Hz
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
AC input voltage: 100 - 240 V
Energy efficiency class (HDR): Not available
Power supply type: Internal
Energy efficiency class (SDR): F
Power consumption (typical): 32 W
Power consumption (standby): 0.7 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Depth (without stand): 61 mm
Height (without stand): 437 mm
Depth (with stand): 61 mm
Weight (without stand): 10 kg
Weight (with stand): 10 kg
Width (with stand): 743 mm
Height (with stand): 437 mm
Width (without stand): 742.5 mm
Performance
Operating hours (hours/days): 24/7
NVIDIA G-SYNC: No
AMD FreeSync: No
Packaging data
Package width: 890 mm
Package depth: 155 mm
Package weight: 13.3 kg
Package height: 630 mm
Packaging content
Cables included: AC, USB, HDMI
Quick start guide: Yes
Display
Screen shape: Flat
Display number of colours: 16.7 million colours
Native aspect ratio: 16:9
Contrast ratio (dynamic): 3000:1
Surface hardness: 7H
Display diagonal: 80 cm (31.5")
Display resolution: 1920 x 1080 pixels
Display brightness (typical): 500 cd/m²
Contrast ratio (typical): 3000:1
Viewable size, horizontal: 69.8 cm
HD type: Full HD
Touch technology: Multi-touch
Viewing angle, vertical: 178°
Viewing angle, horizontal: 178°
Panel type: VA
Colour depth: 8 bit
Pixel pitch: 0.3637 x 0.3637 mm
Horizontal scan range: 30 - 68 kHz
Display brightness: 460 cd/m²
Vertical scan range: 47 - 63 Hz
Display diagonal (metric): 80 cm
Touchscreen type: Kiosk
Touchscreen: Yes
Display technology: LED
Viewable size, vertical: 39.3 cm
Response time: 8 ms
Response time measurement type: GTG (Gray to Gray)
Touchscreen technology: Projected capacitive system
Number of simultaneous touchpoints: 30
Display brightness (peak): 500 cd/m²
Multimedia
Built-in speaker(s): No
Built-in camera: No
Ergonomics
Cable lock slot: No
On Screen Display (OSD) languages: Japanese, Traditional Chinese, French, Spanish, English, German, Italian
Cable management: Yes
Wall mountable: Yes
Number of OSD languages: 7
Panel mounting interface: 200 x 200 mm
Plug and Play: Yes
On Screen Display (OSD): Yes
VESA mounting: Yes
Ports & interfaces
HDMI ports quantity: 1
HDCP: Yes
USB Touch port: Yes
VGA (D-Sub) ports quantity: 1
DisplayPorts quantity: 1
HDMI: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Brightness: 460 cd/m²
Mean time between failures (MTBF): 50000 h
Active display area (W x H): 698.4 x 392.8 mm
Supplied AC adapter type: Yes
Depth: 61 mm
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power
Width: 743 mm
Touch method: finger, glove (latex), capacitive stylus
Height: 437 mm
Compliance certificates: EAC, REACH, UKCA, RoHS, CE, WEEE
Weight: 10 kg
International Protection (IP) code: IP65
Positional accuracy: 2 mm
Sustainability
Sustainability certificates: ErP
