Design
Market positioning: Business
Housing material: Metal
Product colour: Black
Front bezel colour: Black
Glass thickness: 6 mm
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power consumption (typical): 32 W
Power supply type: Internal
Power consumption (standby): 0.7 W
Power consumption (off): 0.3 W
Energy efficiency scale: A to G
Energy consumption (SDR) per 1000 hours: 27 kWh
Energy efficiency class (HDR): Not available
Energy efficiency class (SDR): F
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Width (with stand): 743 mm
Depth (with stand): 61 mm
Weight (with stand): 10 kg
Height (with stand): 437 mm
Height (without stand): 437 mm
Depth (without stand): 61 mm
Weight (without stand): 10 kg
Width (without stand): 745.5 mm
Performance
Operating hours (hours/days): 24/7
NVIDIA G-SYNC: No
AMD FreeSync: No
Packaging data
Package height: 630 mm
Package weight: 12.8 kg
Package width: 890 mm
Package depth: 155 mm
Packaging content
Quick start guide: Yes
Cables included: USB, HDMI, AC
Display
Response time measurement type: GTG (Gray to Gray)
Response time: 8 ms
Display resolution: 1920 x 1080 pixels
Contrast ratio (typical): 3000:1
Panel type: VA
Display brightness (typical): 500 cd/m²
Touchscreen: Yes
Screen shape: Flat
Display number of colours: 16.7 million colours
Digital horizontal frequency: 30 - 68 kHz
Display diagonal (metric): 80 cm
Viewing angle, vertical: 178°
Viewable size, horizontal: 69.8 cm
Display diagonal: 80 cm (31.5")
Display brightness: 425 cd/m²
Viewable size, vertical: 39.3 cm
Pixel pitch: 0.3637 x 0.3637 mm
Display technology: LED
Native aspect ratio: 16:9
Horizontal scan range: 30 - 68 kHz
HD type: Full HD
Viewing angle, horizontal: 178°
Touchscreen technology: Projected capacitive system
Touchscreen type: Kiosk
Touch technology: Multi-touch
Surface hardness: 6H
Anti-glare screen: Yes
Colour depth: 8 bit
Number of simultaneous touchpoints: 30
Ergonomics
Plug and Play: Yes
On Screen Display (OSD) languages: Japanese, German, Italian, Traditional Chinese, French, English, Spanish
Number of OSD languages: 7
Panel mounting interface: 200 x 200 mm
VESA mounting: Yes
On Screen Display (OSD): Yes
Cable management: Yes
Ports & interfaces
HDMI ports quantity: 1
DisplayPorts quantity: 1
HDCP: Yes
VGA (D-Sub) ports quantity: 1
Built-in USB hub: No
USB Touch port: Yes
HDMI: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features
Positional accuracy: 2 mm
Depth: 61 mm
Weight: 10 kg
Width: 743 mm
Active display area (W x H): 698.4 x 392.8 mm
International Protection (IP) code: IP65
Height: 437 mm
Mean time between failures (MTBF): 50000 h
IK code: IK07
Touch method: finger, glove (latex), capacitive stylus
Control panel: Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power
Brightness: 425 cd/m²
Compliance certificates: REACH
Logistics data
Products per pallet: 21 pc(s)
Pallet net length: 120 cm
Pallet net height: 2.04 m
Pallet net width: 100 cm
