Design
Product colour: Black
Glass thickness: 3 mm
Front bezel colour: Black
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 50 W
AC input frequency: 50/60 Hz
Power consumption (off): 0.3 W
Power consumption (standby): 0.4 W
Power supply type: Internal
Energy efficiency scale: A to G
Energy efficiency class (SDR): F
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 31 kWh
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
Depth (with stand): 62.4 mm
Height (with stand): 440.7 mm
Width (with stand): 746.2 mm
Bezel width (side): 2.2 cm
Bezel width (bottom): 2.2 cm
Bezel width (top): 2.2 cm
Weight (with stand): 13.2 kg
Network
Ethernet LAN: Yes
Performance
Operating system installed: Android 11
Operating hours (hours/days): 24/7
Palm rejection: Yes
Operating system version: 11
Packaging data
Package height: 560 mm
Package weight: 16.6 kg
Package width: 840 mm
Package depth: 149 mm
USB cable length: 1.8 m
Packaging content
Quick start guide: Yes
Cables included: USB, HDMI, AC
Batteries included: Yes
Remote control included: Yes
HDMI cable length: 1.8 m
Remote control batteries included: Yes
Power cable length: 1.8 m
Thin Client
Processor architecture: ARM Cortex-A73
Display
LED backlight: Yes
Response time: 8 ms
Viewing angle, vertical: 178°
Horizontal scan range: 28 - 160 kHz
Display diagonal: 80 cm (31.5")
Display brightness (typical): 500 cd/m²
Screen shape: Flat
Display resolution: 1920 x 1080 pixels
Display surface: Matt
Pixel pitch: 0.363 x 0.363 mm
Display number of colours: 16.7 million colours
Native aspect ratio: 16:9
Viewing angle, horizontal: 178°
HD type: Full HD
Panel type: IPS
Display technology: LED
Contrast ratio (typical): 1200:1
Viewable size, horizontal: 69.8 cm
Display diagonal (metric): 80 cm
Viewable size, vertical: 39.3 cm
Touchscreen: Yes
Number of simultaneous touchpoints: 40
Touchscreen technology: Projected capacitive system
Surface hardness: 7H
Display brightness: 435 cd/m²
Anti-glare screen: Yes
Colour depth: 8 bit
Maximum refresh rate: 60 Hz
Haze rate: 25%
Response time measurement type: GTG (Gray to Gray)
Multimedia
Built-in speaker(s): Yes
RMS rated power: 20 W
Number of speakers: 2
Ergonomics
Panel mounting interface: 200 x 200 mm
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Danish, Finnish, German, Italian, Dutch, Swedish, Spanish, Polish, English, Norwegian, Russian, Czech, French
VESA mounting: Yes
Number of OSD languages: 13
Ports & interfaces
HDCP: Yes
DisplayPorts quantity: 1
DVI port: No
DisplayPort version: 1.2
HDMI version: 2.0
HDMI ports quantity: 2
USB version: 2.0
RS-232C: Yes
HDCP version: 2.2
USB Touch port: Yes
Compatible operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Certification: TCO Certified, CB, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH
Other features
Depth: 62.4 mm
Weight: 13.2 kg
Ethernet LAN (RJ-45) ports: 1
International Protection (IP) code: IP65
USB connector type: USB Type-A, USB Type-B
Width: 746.2 mm
Height: 440.7 mm
Built-in processor: Yes
Placement supported: Indoor
Control panel: Power
Package volume: 16600 cm³
Active display area (W x H): 698.4 x 392.8 mm
Brightness: 435 cd/m²
Mean time between failures (MTBF): 50000 h
USB ports quantity: 2
Multi-touch: Yes
Compliance certificates: UKCA, cTUVus, TÜV mark, WEEE, CB, EAC, REACH, RoHS, CE
Touch method: stylus, finger, glove (latex)
Positional accuracy: 2.5 mm
Sustainability
Sustainability certificates: ErP
